Simplex Trident Manual page 14

CABLE REEL
COMPARTMENT
85.500±.500
AIR
EXHAUST
AIR
48.750
EXHAUST
29.000
Figure 1 Trident Dimensions
10 — Description and Specification
131.000±.250
120.000
APPROXIMATELY
54.000
REEL CONTROL PANEL
LOCATED UNDER CENTER REEL
199.687±2.500
81.000
LOCAL CONTROL
PANEL
CAMLOK CONNECTION
(4 PER PHASE)
(1 PER GROUND)
DOOR NOT SHOWN
AUTOTRANSFORMER
A
AIR
INTAKE
A
2" CONDUIT
2.500
AIR
INTAKE
YELLOW CLEARANCE
LIGHT & REFLECTOR
PARKING BRAKE
36" CABLE WITH 7 PIN
RV CONNECTOR
DECK STORAGE
ELECTRIC BREAK-AWAY
BATTERY & SWITCH
2 5/16" BALL HITCH
36" SAFETY
CHAIN W/HOOK
23.000" MAX
19.000" MIN
®
