ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
by Stevens Industries, Inc.
of small parts and sharp edges.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2137R
TM2137R
Activity Cube
2-PERSON ASSEMBLY
RECOMMENDED.
IMPORTANT!
Be sure to keep all parts
supported during assembly
to avoid damage. Do not over-
tighten screws or it will damage
the pre-drilled holes;
snug fit is adequate.
HARDWARE / TOOLS INCLUDED
Confirmat Bolt (5)
(Screw Conn HxDc Ni 7mmx50mm)
Hex Wrench
©2018 Stevens Industries, Inc.
1
3594.TM2137.9/25/18
#0964-3185
Due to continuing product development, Stevens reserves the right to change specifications without notice.
Advertisement
Table of Contents
Related Manuals for Stevens Tot mate TM2137R
Summary of Contents for Stevens Tot mate TM2137R
- Page 1 fit is adequate. HARDWARE / TOOLS INCLUDED Confirmat Bolt (5) (Screw Conn HxDc Ni 7mmx50mm) Hex Wrench ©2018 Stevens Industries, Inc. 3594.TM2137.9/25/18 #0964-3185 Due to continuing product development, Stevens reserves the right to change specifications without notice.
- Page 2 Right End (2). Press firmly into place. STEP Ensure that all joints and bolts are tight. This completes the assembly. ©2018 Stevens Industries, Inc. #0964-3185 3594.TM2137.9/25/18 Due to continuing product development, Stevens reserves the right to change specifications without notice.
