Stevens tot mate TM2084R Assembly Instruction Manual

by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2084R
Single-Door Tall Cabinet
Confirmat Bolt (21)
(Screw Conn HxDc Ni 7mmx50mm)
deadbolt
Lock Body (9)
(Lock Deadbolt NI w/Bezel SIAM)
Lock Screw (12)
(Screw Tapp PhFl Zinc #7x.875)
3594.TM2084.10/18/18
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
TM2084R
HARDWARE / TOOLS INCLUDED
(Phillips screwdriver and soft mallet required but not included.)
Lock Core (10)
(Lock Core NI SIAM #001)
Lock Catch (11)
(Strike Plate Lock)
Lock Catch Screw (13)
(Screw Tapp PhTr Zinc #8x.62)
Hex Wrench
Due to continuing product development, Stevens reserves the right to change specifications without notice.
ATTENTION
When ordering parts, give the Model Number and Color of the unit.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
IMPORTANT!
Assembly must be securely attached to
building structure with anchoring devices
of appropriate type, size and quantity in
accordance with applicable codes and
accepted installation practices.
Hinge (15)
(Hinge Blum F/O 120 S/C Dowel)
Hinge Plate (16)
(Hinge Mtg Plate Blum 0mm)
Pull (17)
(Pull 128mm Advtg Bntwr MtNi)
Pull Screw (18)
(Screw Mach PhTr Zinc 8-32x1.00)
©2018 Stevens Industries, Inc.
Door Bumper (14)
(Bumper Press-In 8x2.5mm Head)
Back Screw (20)
(Screw Tapp PhWh Zinc #8x1.25)
Shelf Clip (19)
(Clip Shlf Clr Twin Pin 3/4-1")
#0964-3138
