  • Page 1: Mounting Bracket

    Installation Guide P/N 070430-001 5020 Vehicle Mounting Bracket...
  • Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
  • Page 3 Guidelines for Installing the Vehicle Mounting Bracket The 5020 vehicle mounting bracket is designed to be installed on a vertical or horizontal surface on a vehicle, such as a forklift truck, or in an office setting, such as a desk.
  • Page 4 To install your 5020 vehicle mounting bracket 1. Install the adapter plate on a mounting surface. 2. Attach the 5020 mounting bracket to the adapter plate. 3. Connect the cables (powered kit only). 4. Insert the 5020 in the vehicle mounting bracket.
  • Page 5 5020 Vehicle Mounting Bracket Installation Guide • If you are attaching the mounting bracket to a horizontal surface, position the adapter plate as shown. 2. Using the adapter plate as a template, mark and drill four holes in the mounting surface.
  • Page 6 5020 Vehicle Mounting Bracket Installation Guide To attach the adapter plate to the swivel stand 1. Orient the adapter plate as shown. 2. Attach the adapter plate to the swivel stand with a screw and nut (included in the swivel stand kit) through each of the four holes in the adapter plate and the swivel stand.
  • Page 7 2. Place the 5020 mounting bracket on the adapter plate so that the four fixed screws on the adapter plate fit in the four holes on the 5020 mounting bracket. 3. Attach the 5020 mounting bracket to the adapter plate with a nut over each of the four fixed screws.

  • Page 8: Connecting The Cables

    5020 Vehicle Mounting Bracket Installation Guide Connecting the Cables If you are installing the powered 5020 vehicle mounting bracket, you can connect to a power supply and a serial device such as a printer. Power supply connector The powered bracket can be connected to either a DC or AC power supply. The power supply accessories are sold separately.

  • Page 9: Connecting The Power Cable

    Liechtenstein and Switzerland North America and Central America United Kingdom For more information about ordering these Intermec power supply accessories, please contact your Intermec sales representative. Connecting the Power Cable 1. For a vehicle installation, install the DC power supply. For help, see the instructions included in the DC power supply kit.

  • Page 10: Connecting The Serial Cable

    5020 Vehicle Mounting Bracket Installation Guide Connecting the Serial Cable To connect to a PC, you need the serial cable accessory (Part No. 070268) (sold separately). To connect to a printer, you need a compatible 9-pin RS-232 serial cable (not included).
  • Page 11 5020 Vehicle Mounting Bracket Installation Guide Inserting the 5020 in the Vehicle Mounting Bracket The position of the vehicle mounting bracket handle depends on whether your 5020 has an integrated scanner or a tethered scanner. To insert the 5020 in the vehicle mounting bracket 1.
  • Page 12 5020 Vehicle Mounting Bracket Installation Guide 3. Pull the handle over the 5020 until it rests securely on top of the 5020. If you have a 5020 with a tethered scanner, push the handle toward the back. To remove the 5020 from the vehicle mounting bracket 1.

  • Page 13: Important Safety Information

    Note: In order to maintain compliance with FCC Rules, the I/O cables that interconnect between the device and any peripheral must be as specified by Intermec. Caution Changes or modifications not expressly approved by Intermec could void the user’s authority to operate this equipment.
  • Page 14 5020 Vehicle Mounting Bracket Installation Guide Additional EMI/RFI Compliance This device meets the Class B limit requirements of CISPR 22. This device complies with AS/NZS 3548 and other applicable rules under the Australian EMC framework. Pour les utilisateurs en dehors du Canada et des Etats- Unis Déclaration de conformité...
  • Page 15 5020 Vehicle Mounting Bracket Installation Guide Para usuarios fuera de Canada o de los Estados Unidos Declaración de conformidad europea Este producto cumple con las normas EN 55022, EN 50082-1 y EN 60950, de acuerdo a lo establecido por la directiva de EMC 89/336/CEE corregida por 92/31/CEE y por la directiva referente al bajo voltaje 73/23/CEE corregida por 93/68/CEE.
