Installation Instructions
Barometric Relief Damper
Precedent™ Packaged Rooftop Units
3 to 12.5 Tons
Model Numbers:
FIABARM001**
FIABARM002**
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
September 2024
Used With:
Precedent A cabinet (Digit 39 = A)
Precedent B and C cabinet (Digit 39 = B, C)
ACC-SVN262B-EN
SAFETY WARNING
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Trane Precedent FIABARM001 Series
Summary of Contents for Trane Precedent FIABARM001 Series
- Page 1 Installation Instructions Barometric Relief Damper Precedent™ Packaged Rooftop Units 3 to 12.5 Tons Model Numbers: Used With: FIABARM001** Precedent A cabinet (Digit 39 = A) FIABARM002** Precedent B and C cabinet (Digit 39 = B, C) SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
-
Page 2: Warnings, Cautions, And Notices
Chlorine, Fluorine and Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all refrigerants containing these compounds have the same potential impact to the environment. Trane advocates the responsible handling of all refrigerants. - Page 3 R-454B, contact your local representative. Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.
-
Page 4: Revision History
Introduction Revision History • Used with model number information updated. • Updated Parts List sections in General Information. ACC-SVN262B-EN... -
Page 5: General Information
General Information Carefully review installation instructions. Note: This instruction covers installation of FIABARM001* and FIABARM002*. Inspection 1. Unpack all components of the kit. 2. Check carefully for shipping damage. If any damage is found, report it immediately, and file a claim against the transportation company. -
Page 6: Hazardous Voltage
Factory Installed Barometric Relief Setup WARNING Hazardous Voltage! Failure to disconnect power before servicing could result in death or serious injury. Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/tagout procedures to ensure the power can not be inadvertently energized. Verify that no power is present with a voltmeter. - Page 7 Factory Installed Barometric Relief Setup 4. Remove the screw (H) holding (B), (C), and (D) together. 5. Remove the screw (I) holding (E) and (F) together. Figure 3. Remove individual screws 6. Attach (B) to (D), and (E) to (F). The results are the assembled rain shield (J) and internal hood (K) shown in Figure 4, p.
- Page 8 Field Installed Barometric Relief Setup Figure 5, p. 8 Figure 6, p. 1. Separate (J) (and C) from the assembly of (A) and (K). Figure 5. Damper assembly 2. Insert (C) into (J) and verify (C) is properly seated. 3. Attach (J) to (A) as shown. Figure 6.
- Page 9 Install Damper into Unit WARNING Hazardous Voltage! Failure to disconnect power before servicing could result in death or serious injury. Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/tagout procedures to ensure the power can not be inadvertently energized. Verify that no power is present with a voltmeter.
- Page 10 Notes ACC-SVN262B-EN...
- Page 11 Notes ACC-SVN262B-EN...
- Page 12 For more information, please visit trane.com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
