INSTALLER'S
GUIDE
ALL phases of this installation must comply with NATIONAL, STATE, AND LOCAL CODES
Models:
Used With:
BAYOSAH001
A5PA*, A5PG*, A5PH*, *DC**, *TC**, *WC**, *YC**018-036
BAYOSAH002
A5PA*, A5PG*, A5PH*, *DC**, *TC**, *WC**, *YC**042-060
Note: * indicates an alphanumeric character.
IMPORTANT - This document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
SHEET METAL
SCREWS
A. GENERAL
These instructions do not purport to cover all variations
in systems nor provide for every possible contingency
to be met in connection with installation. Should
further information be desired or should particular
problems arise which are not covered sufficiently for the
purchaser's purposes, the matter should be referred to
the manufacturer.
PLATE
RAIN HOOD
ADJUSTER
Figure 1. Install BAYOSAH
18-HE39D7-3C-EN
SCREW PANEL
IN PLACE
Check for transportation damage after kit is unboxed.
Report promptly, to the carrier, any damage found to kit.
25% Manual
Fresh Air Kit
