Page 2: Important Safety Notice
Important safety notice Please read below safety instructions carefully before installation and operation: 1. Please pay attention to all the warnings and hints on this device. 2. Do not expose this unit to rain, moisture and liquid. 3. Do not put any stuff into the device. 4. -
Page 3: Package Contents
many, many to many and video matrix connection. It can be widely applied in CCTV, outer large screen, shopping mall advertisement, media education and digital KVM fields etc. 2 Features 1) Full compatible with HDCP. 2) Transmit up to 700meters with RG6(75-5) at 1080P@60Hz. 3) Support up to 100 channels. -
Page 4: Panel Description
3.RG6(75-5) or upper level coaxial cables. 4. INSTALLATION REQUIREMENTS 5 Panel description 1. HDMI to RF sender TX 2.RF to HDMI receiver RX 3.Channel parameters settings... - Page 5 There are 100 (0-99) channels controlled by 2 buttons. Button left can select single digit and button right fortens digit. Combination of tens digit and single digit makes 99 channels totally. TX and RX can build connection only when they are set to same channel parameters and RX HDMI port outputs the corresponding A/V content.
- Page 6 6.2 One-to-many conection：Connect one CATV splitter to realize splitter function. 6.3 Many to many connection：Connect two CATV splitters to build video matrix. Note: for above“CATV splitter 1”, it needs to take“OUT”as the signal input and“IN”as signal output. For“CATV splitter 2”, just follow the marks on the panel description. 6.4 Other notes 1.
- Page 7 When using CATV splitter for 1 to many and many to many connection, it is suggested to use low consumption, high isolation and shielding 5-1000Mhz bi-directional communication splitter to build video matrix. 7 FAQ Q. It shows “NO SIGNAL” on screen? A：1) Make sure to set TV source signal to the correct channel.
-
Page 8: Specification
8 SPECIFICATION Appendix 1:Channel, frequency, cable distance mapping table... - Page 12 Note: Above cable length value is offered based on RG6 (75-5) cable transmission. Professional ones can calculate the transmission length for different material cables by referring to appendix 1 and 2. For example, from appendix 1, it shows channel 5 receive sensitivity is -80dBm. From appendix 2, it shows 700 meters RG6 cable signal loss value is -61.91 dBm at 211Mhz.
-
Page 13: Appendix 2: Coaxial Cable Signal Loss Table
range. To achieve stable signal transmission, it needs to consider the signal loss caused by cables and connectors quality and leave more dBm. Appendix 2: coaxial cable signal loss table website: http://www.net-comber.com/cable-loss.html Disclaimer * The product name and brand name may be registered trademark of related manufacturers.TM and ? may be omitted on the user manual.
