Summary of Contents for KAMEHA KA132PRO
- Page 1 18Gbps HDMI over Optical Fiber Extender with Audio Extracting VER 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
1. Introduction This HDMI Extender can extend HDMI signal up to 3300 feet/1000 meters (over single-mode fiber cable) or 1000 feet/300 meters (over multi-mode fiber cable). Video resolution is up to 4K2K@60Hz 4:4:4. Transmitter supports loop output, audio embeding and EDID managment function. Receiver supports audio extracting function. -
Page 4: Package Contents
3. Package Contents ① 1× 18Gbps HDMI over Optical Fiber Extender (Transmitter) ② 1× 18Gbps HDMI over Optical Fiber Extender (Receiver) ③ 1× IR Blaster cable (1.5 meters) ④ 1× IR Receiver cable (1.5 meters) ⑤ 2× 5V/1A Power adapter ⑥... -
Page 5: Operation Controls And Functions
Input: 1 x Optical Fiber In [LC female] 1 x IR IN [3.5mm Stereo Mini-jack] 1 x SERVICE [Micro USB, Update port] Receiver Output: 1 x HDMI OUT [Type A 19-pin female] 1 x RS-232 [3.81mm Phoenix connector] 1 x IR OUT [3.5mm Stereo Mini-jack] 1 x AUDIO OUT [3.5mm Stereo Mini-jack] Mechanical Housing... - Page 6 Name Function Description The power indicator is always on when the Transmitter is Power LED powered on. The optical fiber connection indicator is always on when the FIBER LED Transmitter and Receiver establish a normal optical fiber signal connection. IN: The HDMI signal input indicator is always on when there is signal input on the HDMI IN port.
-
Page 7: Receiver Panel
5.2 Receiver Panel SERVICE POWER FIBER HDMI IR IN IR OUT DC 5V HDMI OUT AUDIO OUT RS-232 FIBER Name Function Description The power indicator is always on when the Receiver is Power LED powered on. The optical fiber connection indicator is always on when the FIBER LED Transmitter and Receiver establish a normal optical fiber signal connection. -
Page 8: Ir Pin Definition
5.3 IR Pin Definition IR Receiver and Blaster pin’s definition as below: IR RECEIVER IR BLASTER IR Blaster IR Blaster Signal Power IR Receiver IR Signal Power Grounding 5.3 Optical Fiber Module ① SFP-BL35T1-02DC is the optical fiber module of the Transmitter. ②... -
Page 9: Application Example
6. Application Example IR Receiver IR Blaster HDMI SERVICE LINE POWER FIBER LOOP AUDIO EDID HDMI IR IN IR OUT Transmitter OPTICAL DC 5V HDMI OUT HDMI IN LINE IN RS-232 FIBER Power Supply DVD or Blu-ray Player UHDTV Laptop Optical fiber cable Speaker Projector...
