User's Manual – PGT
Part No.: 7100.PGT130.DT
Important settings:
The time zone, date and time must first be set in System settings
After saving the settings and logging in you find the optional sections Device, Network and Advanced
in the Configuration menu.
Optional settings:
Configure measure voltage, measure mode and limit values in section Device.
•
If desired you can configure a fixed IP-Address in section Network.
•
Settings for User data synchronization are available in section Advanced.
•

Configuration

Administration password is required for configuration. The default login is User: admin Password:
admin. The user can change the password.
System settings
·
Company name or independent text. This
will be printed on the first line of each label.
The user ID can be printed instead, if user
identification is enabled and this field is
blank.
·
WEB-interface language
·
Set the date
·
Set the time
·
Select current time zone
·
Print assigned IP-Address after each
system start-up
·
Reboot the terminal
·
Change the configuration password
·
System reset (measurement data and
settings will be erased)
·
Firmware upload
·
DHCP hostname configuration
Measurement data
·
Select amount of records to be viewed in
measurement data view
·
Enable or disable colored marking of failed test
·
Download measurement data as CSV file
·
Clear all measurement data
Label printer
·
Enable or disable the Label printer. Select "ID<99" to print the
·
label only if the entered user ID has less than three characters.
·
Printer and paper selection
·
Delete pending print jobs
