Technical Information
Page 1 of 4
Part No.: 7100.PGT2000.NET
♦ Untere Gießwiesen 21 ♦ 78247 Hilzingen ♦ Tel.: +49-7731-86880 ♦ Fax: +49-7731-868830
PGT 2000 Personnel Grounding Tester
(Part No.: 7100.PGT2000.NET )
Measures personnel grounding including user`s identification and test values documentation
(required by DIN ISO 9000 for example).
Simultaneous measurement of wrist strap and footwear according to DIN EN 61340-5-1
Measurement takes < 1,5 sec for personnel identification, wrist strap and footwear tests
Separate right and left foot test values
Transponder personnel identification system
Access control of protected zones and EPA's through the door opener
Audible and visible test signal
Progammable test voltage and resistance values
Configuration and data transfer through the RS232 port or the Ethernet network card
Integral memory for saving personnel data and test values
(20.000 test values and 5.000 personnel records)
Network connection of up to 64 instruments
Including operating software, MS-Windows® 95/98/NT/2000 compatible, PGT 2000 Manager
Includes:
PGT built-in network card, shoe-testing electrode, wall mounting plate, external power supply 230
VAC, RS 232 null modem cable, CD-ROM "PGT 2000 Manager" installation program, user`s manual
in English and German and a calibration certificate.
Unit description:
wrist strap test
LED indicator
upper limit exceeded
LED indicator
below low limit
Male snap 3mm
Keyboard for
special function
LED indicator
identification failed
We believe all the information in these pages including technical data to be reliable. However we make no warranties
expressed or implied and assume no liability regarding any use of this information.
wrist strap connector
wrist strap test
Display
Display
Button for
Button for
footwear test
footwear test
LED indicator
upper limit exceeded
LED indicator
below low limit
LED indicator
measurement value
in the limit
Dimension:
180 x 264 x 100 mm
V0102
