ISTRUZIONI PER L'USO INSTRUCTIONS FOR USE BEDIENUNGSANLEITUNG UNITÁ CON RULLINO Ø 30 NOTICE D'UTILISATION Ø 30 ROLLER UNIT EINHEIT MIT ROLLE Ø 30 INSTRUCCIONES PARA EL USO UNITE AVEC GALET Ø 30 UNIDAD CON RODILLO Ø 30 EENHEID MET ROL Ø 30 GEBRUIKSAANWIJZING...
Page 2
Le caratteristiche tecniche dell'ELASTOGEL sono: elevata elasticità,resistenza alla lacerazione, all'abrasione e resi- stenza agli oli e ai solventi. ELITE ist stolz, ein weiteres Produkt präsentieren zu können, das in Zusammenarbeit mit dem Chemiekonzern BAYER *DECIBEL entstanden ist: ELASTOGEL. Bei ELASTOGEL handelt es...
Page 3
60 dB zehnmal so laut ist, wie ein Geräusch, das mit 50 welke de onderstaande voordelen biedt: dB gemessen wurde. ELITE, en collaboration avec BAYER, à étudié l'ELASTOGEL il s'agit d'un technopolymer appliqué au rouleau d'entraine- ment ,qui offre les aventages suivants:...
• IMPORTANTE • INTRODUZIONE • MONTAGGIO UNITÀ POWER MAG • RIMOZIONE DELLA BICICLETTA • IMPORTANT • INTRODUCTION • FITTING THE POWER MAG UNIT • BICYCLE REMOVAL • WICHTIGER HINWEIS • EINLEITUNG • MONTAGE DER EINHEIT POWER MAG • ABNEHMEN DES FAHRRADES...
Page 5
• INTRODUCTION • ASSEMBLAGE UNITE POWER MAG • ENLEVEMENT DU VÉLO • IMPORTANTE • INTRODUCCIÓN • MONTAJE UNIDAD POWER MAG • CÓMO SACAR LA BICICLETA • BELANGRIJK • INLEIDING • MONTAGE VAN DE POWER MAG EENHEID • DE FIETS VERWIJDEREN...
Molte grazie per aver acquistato un rullo d'allenamento Elite IMPORTANTE Non frenare durante l'utilizzo del trainer, ciò danneggia irreparabilmente il rullino e il pneumatico L’unità di resistenza si riscalda sensibilmente quando in uso. È necessario aspettare che si raffreddi prima di toccare il volano Non ci sono componenti utilizzabili singolar- mente all’interno.
MONTAGGIO UNITÀ POWER MAG • Unità con rullino Ø 30 mm. • Per il montaggio dell’unità al telaio, atte- nersi alle istruzioni presenti nel manuale del telaio. • Fissare la manopola di regolazione facen- do attenzione che il cavo di regolazione non entri in contatto con le parti in movimento della bicicletta.
Congratulations on your purchase of an Elite hometrainer IMPORTANT Do not stop the rotation of the bicycle wheel by using caliper or disk brake. This seriously damages the roller and the tire The resistance unit may warm-up while in use. Let it cool down before handling it and touching the flywheel There are no user serviceable parts.
FITTING THE POWER MAG UNIT • 30 mm diameter roller unit. • To fit the unit on the frame, follow the instructions provided in the Frame manual. • Tighten the adjusting handle while care- fully checking that the shift cable does not touch any moving parts of the bike.
Wir danken Ihnen für den Kauf eines Elite Heimtrainers WICHTIGER HINWEIS Während des Gebrauchs des Heimtrainers auf keinen Fall bremsen, da sonst die Rolle und die Reifen stark beschädigt werden kön- nen! Die Widerstandseinheit erwärmt sich beim Gebrauch spürbar. Bitte lassen Sie sie abkühlen, bevor Sie das Schwungrad anfas-...
MONTAGE DER EINHEIT POWER MAG • Einheit mit Rolle Ø 30 mm. • Zur Montage der Einheit am Rahmen die in der Bedienungsanleitung des Rahmens enthaltenen Anweisungen beachten. • Die Einstelleinheit befestigen, wobei darauf geachtet werden muss, dass das Kabel nicht mit den beweglichen Teilen des Fahrrads in Berührung kommt.
Merci d’avoir acheté un rouleau d'en- traînement Elite IMPORTANT Ne pas freiner pendant l’utilisation du trai- ner, ceci endommage irréparablement le rou- leau et le pneu L'unité de résistance chauffe sensiblement lors de son utilisation. Laissez-la refroidir avant de toucher le volant Les composants internes ne peuvent pas être...
ASSEMBLAGE UNITE POWER MAG • Unité avec galet Ø 30 mm. • Pour l’assemblage de l’unité au cadre respectez les instructions présentes dans le manuel du Cadre. • Fixer le bouton de réglage en veillant à ce que le câble de réglage ne touche pas les éléments en mouvement du vélo.
Muchas gracias por adquirir un rodillo de entrenamiento Elite IMPORTANTE No frenen durante el uso del trainer, pues se dañarían sin remedio el rodillo y el neumático La unidad de resistencia se calienta sensible- mente durante el uso. Es necesario esperar a que se enfríe antes de tocar el volante...
MONTAJE UNIDAD POWER MAG • Unidad con rodillo Ø 30mm • Para el montaje de la unidad al bastidor, atenerse a las instrucciones presentes en el manual del Bastidor. • Fijar el dispositivo de regulación poniendo atención que el cable de regulación no entre en contacto con las partes en movi- miento de la bicicleta.
Gefeliciteerd met de aankoop van uw Elite trainer BELANGRIJK Rem niet tijdens het gebruik van het trai- ningstoestel; hierdoor kan de rol en de band onherstelbaar beschadigd worden De weerstandsunit wordt tijdens gebruik erg heet. Daarom moet u de unit eerst af laten...
MONTAGE VAN DE POWER MAG EENHEID • Eenheid met rol Ø 30 mm. • Om de eenheid aan het frame te monteren moet u zich aan de aanwijzingen houden die in de handleiding van het frame staan. • Bevestig de stelknop en let er daarbij op dat de stelkabel niet in contact komt met de bewegende delen van de fiets.
