ENGLISH
®
Thank you for buying this JB Systems product. To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
 This device has been designed to produce decorative effect lighting and is used in light show systems.
 Stylish RGB LED-projector containing high-power 5mm LEDs:
 LED-PAR56: 156pcs (50 red + 53 green + 53 blue)
 LED-PAR64: 212pcs (70 red + 71 green + 71 blue)
 Beam angle = 15°
 Optional frost filters can be installed in the supplied filter frame to obtain a nice flood beam.
 Many applications possible: Discotheques, DJs, exhibition booths, homes, ...
 Very smooth RGB color changes thanks to high freq. dimming electronics: 400Hz !
 Different working modes:
 Completely standalone: automatic or beat synchronized color changes (optional CA-8 controller
possible)
 Master/slave mode: up to 16 units can be used together for wonderful preprogrammed, music
synchronized lightshows. (optional CA-8 controller possible)
 DMX-controlled (4channels: R, G, B + Dimmer/strobe/sound chase) by any standard DMX-controller.
 Used with LEDCON 01 remote control
 Different ways to set DMX start address:
 Very easy DMX addressing of individual units using any standard DMX-controller
 Extremely fast DMX addressing of several units at once (automatic address calculation)
 Traditional DMX-setting by DIP-switches
 Can be fixed to any surface, can also be fixed in ALU-truss using a standard clamp.
 High quality "Hewlett Packard ® ® "
/ Agilent LED technology: >100.000 hours!

BEFORE USE

 Before you start using this unit, please check if there's no transportation damage. Should there be any, do
not use the device and consult your dealer first.
 Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
 Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check that the carton contains the following items:
 Operating instructions
 LED Projector (PAR56 or PAR64)
 Hanging bracket
 2 Knobs to fasten the hanging bracket
 Filter frame
JB SYSTEMS
®
OPERATION MANUAL
1/47 LED PAR 56/PAR64
ENGLISH

SAFETY INSTRUCTIONS:

CAUTION: To reduce the risk of electric shock, do not remove the top cover.
CAUTION
No user-serviceable parts inside. Refer servicing to qualified service
personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use
or the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.
This symbol means: indoor use only.
This symbol means: Read instructions.
 To protect the environment, please try to recycle the packing material as much as possible.
 To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
 To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when
bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full
performance or may even cause damages.
 This unit is for indoor use only.
 Don't place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign
object enters the unit, immediately disconnect the mains power.
 Prevent use in dusty environments and clean the unit regularly.
 Keep the unit away from children.
 Inexperienced persons should not operate this device.
 Maximum save ambient temperature is 40°C. Don't use this unit at higher ambient temperatures.
 Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
 Always unplug the unit when it is not used for a longer time or during servicing.
 The electrical installation should be carried out by qualified personal only, according to the regulations for
electrical and mechanical safety in your country.
 Check that the available voltage is not higher than the one stated on the rear panel of the unit.
 The power cord should always be in perfect condition: switch the unit immediately off when the power cord
is squashed or damaged.
 Never let the power-cord come into contact with other cables!
 This fixture must be earthed to in order comply with safety regulations.
 Don't connect the unit to any dimmer pack.
 Always use an appropriate and certified safety cable when installing the unit.
 In order to prevent electric shock, do not open the cover. Apart from the mains fuse there are no user
serviceable parts inside.
 Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same
type and electrical specifications!
 In the event of serious operating problems, stop using the fixture and contact your dealer immediately.
 The housing and the lenses must be replaced if they are visibly damaged.
 Please use the original packing when the device is to be transported.
 Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
Important: Never look directly into the light source! Don't use the effect in the presence of persons suffering
from epilepsy.
