mr. steam AromaFlo Installation, Operation & Maintenance Manual
Fragrance metering pump system for commercial steam rooms
Hide thumbs
Also See for AromaFlo:
- Installation & operation manual (8 pages) ,
- Installation, operation & maintenance manual (20 pages) ,
- Installation, operation & maintenance manual (20 pages)
Table of Contents
Advertisement
Quick Links
Installation, Operation & Maintenance Manual
Fragrance Metering Pump System for
Commercial Steam Rooms
__________________________________
IMPORTANT: Leave this material with the operator.
__________________________________
.
mr
steam
!
WARNING
This installation, operation and maintenance manual is for general reference.
The installation, operation and maintenance manual supplied with the product must be used for
installation, operation and maintenance purposes. Failure to use the installation, operation and
maintenance manual supplied may result in a property damage or personal injury.
AromaFlo
Part Number CU-AROMAFLOA
l
®
Feel Good Inc.
®
Advertisement
Table of Contents
Related Manuals for mr. steam AromaFlo
Summary of Contents for mr. steam AromaFlo
- Page 1 Installation, Operation & Maintenance Manual AromaFlo Fragrance Metering Pump System for Commercial Steam Rooms Part Number CU-AROMAFLOA __________________________________ IMPORTANT: Leave this material with the operator. __________________________________ steam Feel Good Inc. ® ® WARNING This installation, operation and maintenance manual is for general reference.
-
Page 2: Table Of Contents
Read these instructions before installation or service. Although Important Safety Information ....4 the AromaFlo pump has been fully qualified for shipment by System Overview ........5 MrSteam, the following must be reviewed for proper, safe and General System Dimensions ....6... -
Page 3: Box Contents
® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N Box Contents Pump Caddy Pressure Tube Suction Tube Assembly Assembly REDUCE THE RISK OF OVERHEATING AND SCALDING WARNING! 1. - Page 4 If condition cal sized commercial steam room. Start with the persists get medical attention. AromaFlo dispensing pump volume at a very low setting. Gradually increase the volume setting until CU-EUCALYPTUS, CU-LAVENDER a comfortable fragrance level is reached. Do not are only for use with the MrSteam AromaFlo exceed the “...
-
Page 5: System Overview
® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N AromaFlo System Overview Steamline Pump Line Cord Steam Solenoid Steam Head with Outlet Check Valve Pressure Tube Pump... -
Page 6: General System Dimensions
® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N General System Dimensions 5 -10 ft. optimal Steam Pipe T Steam Generator Steam Solenoid Check Valve Steam Head... - Page 7 5. Do not install the AromaFlo System outdoors. 6. Do not install the AromaFlo System in a location where water could freeze. 7. Do not install the AromaFlo System near corrosive materials and chemicals.
- Page 8 The Check Valve prevents excessive amounts of fragrance from entering the steam line and steam room. Never Tube Holder install the AromaFlo System without the Check Valve. Failure to Collar install the Check Valve may result in excessive fragrance delivery into the steam room and cause dizziness and/or personal injury.
- Page 9 ® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N SUCTION TUBE ASSEMBLY For your convenience the suction tube assembly is provided preassembled. If additional tubing is needed please contact MrSteam Technical service at 1-800-767-8326 or 1-800-727-8326.
- Page 10 ® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N Priming the Pump 1. Insure MrSteam fragrance container is full. 2. Insert a short piece of soft injector tube onto the tip of the injector (see Fig.
- Page 11 CU AROMAFLO This AromaFlo system is CAUTION factory wired. If the power cord of the AromaFlo pump is damaged it must be replaced by the MrSteam service depart- ment or similarly qualified personnel in order to avoid an electric shock hazard.
-
Page 12: Operation
The LED will turn off each time the pump injects fragrance into the steam line. No Light Pump is OFF The AromaFlo pump will inject a metered amount of fragrance into the steam line only when the steam solenoid valve is open. Adjusting the Amount of Fragrance Delivery... -
Page 13: Troubleshooting
Rinse foot valve under clean water. ELECTRICAL SHOCK HAZARD. MrSteam WARNING AromaFlo pumps are connected to 120V line voltage and contain live electrical components. All installation Pump does not inject fragrance into and service to be performed by qualified and licensed steam room electricians and plumbers only. -
Page 14: Replacement Parts
® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N REPLACEMENT PARTS Check Valve (5 pcs.) 104240 Tube (per foot) 104255 O-Ring Kit (3 pcs.) 104275 Tube Connector... -
Page 15: Installing The Caddy
® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N Pump Installing the Caddy: Box Contents: Tools required: a Phillips bit * Use only non-sparking tools. Take precautionary measures... - Page 16 ® AromaFlo Operation and Installation Instructions I N S T A L L E R S E C T I O N Mounting the Caddy on a Wall: 1. Use a level to make sure the caddy is level. 2. Use the two mounting screws provided to secure the caddy to a wall stud (Diagram 2).
- Page 17 –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– The Safety Data Sheet provides comprehensive information about MrSteam AromaFlo fragrances. Contact 1-800-767-8326 or go online at www.mrsteam.com for a copy of the Safety Data Sheet. MrSteam AromaFlo Fragrances IMPORTANT NOTE: As you follow these instructions, you will notice warning and caution symbols.
-
Page 18: Warranty
If condition cal sized commercial steam room. Start with the persists get medical attention. AromaFlo dispensing pump volume at a very low setting. Gradually increase the volume setting until CU-EUCALYPTUS, CU-LAVENDER a comfortable fragrance level is reached. Do not are only for use with the MrSteam AromaFlo exceed the “... - Page 19 No Light Pump is OFF The AromaFlo pump will inject a metered amount of fragrance into the steam line only when the steam solenoid valve is open. Adjusting the Amount of Fragrance Delivery The AromaFlo system has been factory set to deliver a suitable amount of aromatic fragrance into a typical sized steam room.
- Page 20 : 1 800 72 STEAM 2020 © MrSteam and des., A Lifetime of Pleasure, AirTempo, AromaFlo, AudioWizard, AutoFlush, AutoSteam, Butler Package, ChromaSteam, Clean Steam...Every Time, Club Therapy, CT Day Spa, Digital 1, Express Steam, Feel Good Inc., From Bathroom to Spa, HomeWizard, iButler, iGenie, iSpa Package, iSteam, iTempo, iTempo/Plus, Linear Steamhead, Making Wellness a Way of Life, Music Therapy, My Steam, SmartSizing, Spa Package, Steam Genie, Steam on Demand, Steam in a Box, Steam@Home, SteamStart, SteamTherapy, Tala, Tala Bath &...
