mr. steam AromaFlo Installation & Operation Manual
Fragrance metering pump
for commercial steam rooms
Hide thumbs
Also See for AromaFlo:
- Installation, operation & maintenance manual (20 pages) ,
- Installation, operation & maintenance manual (20 pages) ,
- Installation, operation & maintenance manual (20 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for mr. steam AromaFlo
Summary of Contents for mr. steam AromaFlo
- Page 1 Installation & Operation Manual AromaFlo ® steam ® Feel Good Inc. ®...
-
Page 2: Table Of Contents
Filling the Pressure hose WARNINGs Operation • Do not use with water soluble fragrance or fragrance Powering up Pump containing emulsifiers or aldehydes. AromaFlo Adjusting oil delivery Pump system damage may result. Mrsteam oils are approved for operation with this system. Troubleshooting •... -
Page 3: Box Contents
Tubing Connections 2. do not install AromaFlo Pumps outdoors. Tube Holder 1. completely unscrew tightening nut 3. do not install AromaFlo Pumps in a location from pump head (or fitting) and where water could freeze. remove components 4. do not install AromaFlo Pumps near flammable 2. -
Page 4: Pump Assembly
Pressure Hose Repeat the suction hose installation steps on the pressure side of the pump. Mrsteam recommends installing the AromaFlo lower than the Atomizing nozzle. If the pump must be installed higher that the atomizing nozzle a loop should be placed in the pressure tubing to prevent siphoning as required. -
Page 5: System Schematic
For illUSTrATiVE PUrPoSES oNly (see full disclaimer) __________________________________ _____________________________________________________________________ ElECTRICAl CONNECTION Of METERING PUMP Digital 1 Control and CU-Aromaflo Wiring schematic this meter- CAUTION ing pump is factory wired and CU Steam Generator Digital 1 Control operates on 120VAC 50/60hZ... -
Page 6: Assembly Diagram
ElECTRICAl bOx AssEMblY Receptacle Faceplate (supplied with AromaFlo) CAUTION to avoid possible electric shock, the AromaFlo pump must be suitably grounded according to National electric and local codes. disconnect all power supplies single Receptacle (supplied with AromaFlo) before proceeding. such wiring should be done by a licensed electrician. -
Page 7: Start-Up
Adjusting the Amount of Oil Delivery RECOMMENDED SETTING the AromaFlo system has been factory set to deliver a suitable amount of aromatic oil into a typical sized steam room. Please contact the Mrsteam technical service department before changing this setting. -
Page 8: Troubleshooting
8. ensure the pump has been powered up. see page 7. Metering pump oil delivery too much or too little WARNING the AromaFlo system has been factory set to deliver a suitable amount of aromatic oil into a typical sized steam room. Please contact the Mrsteam technical service department before changing this setting.
