6. With Industrial-grade design, it has thickened 6-layer PCB
board, 16KV super anti-static ability, and tremendous stability.
7. Any splicing needs can be customized according to user
needs.
1.2. Application scenarios
Ultra-high resolution desktop applications, ultra-large screen
walls, command and dispatch systems, multi-screen video
surveillance, engineering display applications, multi-channel
projection, virtual reality, surround-screen theater, large
advertising walls, LCD/LED multi-screens, etc.

2. Specifications

Product name
Input Max. Pixel FPS
Output Max. Pixel FPS
4x4 highest resolution
7x2 highest resolution
2x7 highest resolution
Shenzhen Bitvisus technology limited. Video News Co., Ltd
BIT-MSE-U1-312 Ultra HD splicing
processor
600MHz
165MHz
7680x4320@60Hz
3840x7560@60Hz
13440x2160@60Hz
