D25 User Manual
Warning:
The drone is for flying both indoors and outdoors. Please keep away from any obstacles.
Keep a fixed distance from people and pets, and do not play in an unsafe environment,
such as a heat source, electric wire or power line and some bad weather which may
lead to loss of life and property or even electric shock. The wind level is not more than 4
levels.
The product is suitable for children over 14 years old. It is recommended that kid's
playing needs an adult's supervision.
DANGER
Only suitable
for age 14+
Advertisement
Table of Contents
Related Manuals for TOMZON D25
Summary of Contents for TOMZON D25
- Page 1 DANGER Only suitable for age 14+ D25 User Manual Warning: The drone is for flying both indoors and outdoors. Please keep away from any obstacles. Keep a fixed distance from people and pets, and do not play in an unsafe environment, such as a heat source, electric wire or power line and some bad weather which may lead to loss of life and property or even electric shock.
-
Page 2: Propellers Installation
Main Body Power switch Propeller WIFI Camera Motor Propellers Installation The propellers need to be replaced in relative positions on the drone. Propeller A must be installed at position A. Propeller B must be installed at position B. If the propeller is replaced in wrong position, the drone will not take off. -
Page 3: Battery Installation
Introduction of transmitter Headless Mode(Short press) One-button Return(Long press) Photo Taking One-key Take off / land(Short press) Emergency Landing(Long press) Video Recording Fine Tuning Power Switch Throttle Joystick / Speed Direction Joystick Gear(Press down the Flip(Press down middle key) the middle key) Battery Installation Open the battery on the back of remote controller. - Page 4 Make sure the propeller is installed correctly and fastened. 2.Frequency Pairing: 1. Press the power button to start the remote control. After turning on the remote controller and the drone, push the left joystick forwards and downwards successively. The drone LED lights stably, wait for a few second, the drone is ready to fly.
- Page 5 When the left throttle joystick push up or pull down, the quadcoper is ascending or descending. When push the throttle joystick left / right, the drone will turn left / right. When push the throttle joystick forwards / backwards, the drone will fly forwards / backwards.
- Page 6 2. Drone forwards and backwards: when the 3. Steering operation: when the drone is drone is hovering in the air, push the right hovering in the air, push the right joystick joystick forwards / backwards and the left / right and the drone will perform left / drone will fly forwards / backwards right side flight.
- Page 7 The blades are not running The blade A and blade B are The blade A and blade B should be installed mistakenly. installed correctly. Drone battery power is depleted. Take out the objects that stuck in Get stuck with somthing the motors Motors are not running Control distance beyond...
- Page 8 DRONE Flying weight: 115g Flight time: about 12 minutes Working ambient temperature: 0~40° C Working frequency: 2.402 - 2.483GHz CAMERA Maximum resolution: 4096*2160 Controllable range of rotation: +0° - 90° Video resolution: 1920*1080P Picture format: JPG Video format: MP4 REMOTE CONTROLLER Working frequency: 2.402 - 2.483GHz Maximum effective distance of signal: 60m (under environment with no interference and no occlusion)
-
Page 9: App Instruction
App Instruction App installation instructions Reminders Operation interface (1) introduction to the operation interface (2) control mode (3) interface mode (4) function icon MV interface... - Page 10 App installation instructions 1. Install the mobile client Please scan the QR code below and download the mobile App on the corresponding website. (you can also search for “ Tomzon-T ” in the app marketplace for downloads) Android china） Android（other）...
- Page 11 3. The recommended model configuration (1) iOS Configuration Optimal Recommended (2) Audroid Configuration Optimal Recommended Please clear memory of the background program in time to reduce the CPU usage. Reminder 1 Important Notes: To ensure a better recognition when perform the hand-gesture functions: 1.
-
Page 12: Operation Interface
Reminder 2 When flying in the following environment, the drone's fixed-pointed hovering may not be performed successfully. Operation interface 1. Introduction to operation interface In "flight mode," double-click the white space with your finger can flip the lens. (Some models do not support this feature) -
Page 13: Control Mode
2. Control Mode Virtual Joystick Mode In this mode, the left virtual stick controls the drone up, down, turning left and turning right. The right virtual stick controls forward, backward, left side flight and right side flight.(These operations are under left-hand throttle mode, if the drone is under right-hand throttle mode, then the left and right stick's function should be exchanged) Hidden Mode In this mode, the left virtual stick controls up, down, turning left and turning right of the... - Page 14 Illustration on the Functions of Icon Other Functional Icon...
- Page 15 Other Functional Icon...
- Page 16 The MV interface Introduction to MV interface * Rotating picture Click this button to enable the Rotate Screen feature. At this point, the finger swipes on the screen to rotate the image; if the finger double-clicks anywhere on the screen, the image can be magnified in an instant (this feature also applies when recording video).
- Page 17 Please scan the QR code below and download the mobile App on the * Rotating picture corresponding website. (you can also search for “ Tomzon-T ” in the app marketplace for downloads) Click this button to enable the Rotate Screen feature. At...
