- Page 1 Operating manual Butzbach System Anti-drop device...
- Page 2 All rights reserved. This manual may not be reproduced or disseminated in any manner without the prior consent of Butzbach GmbH Industrietore. Butzbach GmbH Industrietore reserves the right to make changes to illustrations and information in this operating manual in order to incorporate technical advances. This operating manual was created with great care and is revised regularly.
-
Page 3: Table Of Contents
Inspection and maintenance of the fall arrestors................3 Reinstallation of the fall arrestors ....................... 3 Inspection of the locking function ....................... 3 Connection and inspection of the automatic shut-off device .............. 4 Technical Data ............................5 Index ................................... 6 Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021... -
Page 4: Functioning Of The Anti-Drop Device System
Each time that it is triggered, e.g. after a fall, the operational readiness of the anti-drop device system must be restored by means of servicing. Areas of use of the anti-drop device system The anti-drop device systems are employed in the following door types from Butzbach GmbH Industrietore. Type Use in door types ®... -
Page 5: Testing The Anti-Drop Device System
Keep evidence of the required checks in the form of a test report. This test report should be placed in the test book. Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021... -
Page 6: Maintenance Of The Anti-Drop Device System
Reinstall the fall arrestors in the correct position through the lower openings in the guide rail. Inspection of the locking function The anti-drop device system is tested for standard installation situations. Therefore, the fall arrestors must only be still tested for proper locking. Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021... -
Page 7: Connection And Inspection Of The Automatic Shut-Off Device
The limit switch is enabled when starting up the door. Afterward, the motor switches off (depending on the setting: 2 seconds of moving freely or opens until the door OPEN end switch is reached) and stops the door movement. Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021... -
Page 8: Technical Data
HT40 / TW PG HT60, HT80/260 HT80 HT150 Drawing number 45 /058/4 45/ 148/4 45/ 105/4 45/ 081/4 Automatic shut-off device By means of Both sides Both sides Both sides overload protection on both sides Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021... -
Page 9: Index
Automatic shut-off device ......... 1, 4 Maintenance ..............3 Copyright ............... I Masthead ............... I Design ................1 Reinstallation ..............3 Dismantling ..............3 Technical Data .............. 5 Fall arrestors..............3 Testing ................2 Function ................ 1 Butzbach GmbH Industrietore Originalbedienungsanleitung Absturzsicherung_V1 24/02/2021...
