MODMO Saigon+ User Manual page 15

3.5. Changing a tyre/tube/wheels
We recommend putting the E-Bike on a service stand to perform a wheel installation and removal. It is the safest, both for the bike
and the user, as well as the easiest way to perform any kind of replacement and maintenance procedures.
It is still possible to perform tyre or wheel changes with the E-Bike upside down but protection should be added on the display to
prevent damage and care must be taken to not tip over the bike.
3.5.1. Removing/Fitting the Front Wheel
You can refer to the videos on Modmo's YouTube channel for further detail on the removal and installation of the front wheel.
Step 1. Unplug the motor cable located on the side of the front
The wheels
electric motor.
are easier to
remove if
you put the
bike into a
service
stand or
place it
upside
down.
Note: If the
front wheel
has been
removed, do
Step 3. Insert the MOD-Nut tool into the MOD-Nut and loosen
not press the
the bolt so it can turn freely without completely removing it and
brake lever.
there is visible space between the nut and the fork/frame. One
hand should hold the front wheel to prevent it from falling while
loosening the MOD-Nuts.
Step 2. Locate the MOD-Nut tool in the rear Modular mount
and attach it to the 16mm spanner provided in the tool box.
Step 4. Carefully remove the front wheel from the dropout.
15
MA IN TE NA NC E
