Unpacking The Speaker - Infinity Total Solutions TSS-Center1100 Owner's Manual

I
NTRODUCTION
Infinity Total Solutions
™
Infinity Total Solutions TSS-CENTER1100 center channel
loudspeaker is designed to perfectly complement Total Solutions
speakers. It provides exceptional dialogue reproduction and a
seamless transition between the front channels.The horizontal
design allows for maximum placement flexibility.
About This Guide
Please read this guide completely before connecting and
operating the TSS-CENTER1100 center channel speaker.
Maximum performance is dependent upon following these
instructions, as well as those in the owner's manuals of
associated components in your home theater system. Save
these instructions for future reference.

Unpacking the Speaker

Finish unpacking the speaker and check the contents. If you
suspect damage from transit, report it immediately to your
dealer. Keep the shipping carton and packing materials for
future use.
Contents
Please verify that the package contains the following items:
(1) TSS-CENTER1100 center channel speaker
(1) Speaker base
P Y S
LANNING OUR YSTEM
Before deciding where to best place your speakers, survey your
room and study Figures 1 and 2.
Center
Left
Channel
Front
(above or below TV)
Channel
Couch
Left
Surround
Channel
Figure 1. In this overhead view of a typical installation, satellite
speakers are used to reproduce sound for the front and surround
channels.The center channel reproduces sound and dialogue.
The powered subwoofer provides bass for effects and music.
Placement
Figure 2.This example shows the TSS-CENTER1100 being placed
on top of a television.The speaker can also be placed below the
television and tilted up (see Figure 3).
Right
Front Subwoofer
Channel
Right
Surround
Channel
