Specifications - Infinity Classia C205 User Manual

S
PECIFICATIONS
Frequency Ranges:
Recommended
Amplifier Power Range:
Sensitivity (2.83V 1 meter):
@
Nominal Impedance:
Crossover Frequencies:
Low-Frequency Driver(s):
Mid-Frequency Driver:
High-Frequency Driver:
Dimensions (H x W x D):
Weight:
Features, specifications and appearance are subject to change without notice.
6 INFINITY CLASSIA
C205
60Hz – 30kHz (–3dB)
55Hz – 40kHz (–6dB)
10 – 125 Watts
88dB
8 Ohms
2.0kHz; 24dB/octave
5-1/4" (133mm) CMMD, ®
magnetically shielded
N/A
1" (25mm) CMMD,
magnetically shielded
15-1/8" x 7-1/2" x 9-1/4"
(384mm x 190mm x 235mm)
10.8 lb (4.9kg)
C336
40Hz – 30kHz (–3dB)
35Hz – 40kHz (–6dB)
10 – 250 Watts
91dB
8 Ohms
500Hz, 2.8kHz; 24dB/octave
Triple 6-1/2" (165mm) CMMD, ®
magnetically shielded
4" (100mm) CMMD,
magnetically shielded
1" (25mm) CMMD,
magnetically shielded
48-3/4" x 8-1/2" x 10-1/2"
(1238mm x 216mm x 267mm)
56.1 lb (25.4kg)
CC225
55Hz – 30kHz (–3dB)
50Hz – 40kHz (–6dB)
10 – 150 Watts
90dB
8 Ohms
2.0kHz; 24dB/octave
Dual 5-1/4" (133mm) CMMD, ®
magnetically shielded
N/A
1" (25mm) CMMD,
magnetically shielded
6-7/8" x 31-3/4" x 5"
(175mm x 806mm x 127mm)
16 lb (7.3kg)
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described
in this owner's manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group, Inc.
Château du Loir, France 12/07
