Fisher & Paykel DW24U6I1 Parts Manual

Fisher & Paykel DW24U6I1 Parts Manual

Hide thumbs Also See for DW24U6I1:

Advertisement

Quick Links

BUILT IN DISHWASHER
DW24U6I1 FP US CA
PRODUCT CODE: 81872-A
PARTS MANUAL
US CA

Advertisement

loading
Need help?

Need help?

Do you have a question about the DW24U6I1 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel DW24U6I1

Summary of Contents for Fisher & Paykel DW24U6I1

  • Page 1 BUILT IN DISHWASHER DW24U6I1 FP US CA PRODUCT CODE: 81872-A PARTS MANUAL US CA...

  • Page 2: Table Of Contents

    CONTENTS Introduction Chassis & Tub components Basket components Spray Arm components Base & flood components Door components...

  • Page 3: Introduction

    MODEL PRODUCT CODE Fisher & Paykel 120VAC 60Hz DW24U6I1 FP US CA 81872-A MODELS The models covered by this manual are listed on the front cover. The information detailed in this manual is subject to change without notice. The latest version is indicated by the reprint date and replaces any earlier editions.

  • Page 4: Chassis & Tub Components

    CHASSIS & TUB COMPONENTS DWG 005221...
  • Page 5 CHASSIS & TUB COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION GASKET TUB H0120300248 SCREW ST3.5 17 H0077010022 LIGHTS INTERIOR H0120400216 DOOR LOCK/HOOK ASSEMBLY H0120801601 HOUSING THERMO DRY H0120802341 GASKET SEALING H0120200605 H0120200604 HOSE THERMO DRY H0120300099C FELT SOUND DEADENING SIDE/TOP H012G1451092A REAR FOOT ADJUSTABLE BUILT IN TUB ASSEMBLY GASKET TUB DOOR GASKET RIGHT...

  • Page 6: Basket Components

    BASKET COMPONENTS DWG 005218...
  • Page 7 BASKET COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION RAIL SUPPORT-PLASTIC H0120200872 RAIL SUPPORT-SS H0120802832 3RD RAIL -LEFT H0120802833 3RD RAIL-RIGHT H0120802833A ENDCAP RAIL H0120200895A H0120201178B KNIFE RACK KNIFE RACK MOVEABLE H0120201178C 3RD RACK SUPPORT-1 H0120101078A 3RD RACK SUPPORT-2 H0120101078B 3RD RACK SUPPORT H0120101078 WHEEL H0120201141...
  • Page 8 BASKET COMPONENTS DWG 005218...
  • Page 9 BASKET COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION FOLD DOWN WIRE-2-LEFT H0120101082B FOLD DOWN WIRE-2-RIGHT H0120101082C CLIP FOLD DOWN H0120202828B WINE GLASS SUPPORT-RIGHT H0120201180E WINE GLASS SUPPORT-LEFT H0120201180F H0120101082 FOLD DOWN WIRE-1-RIGHT FOLD DOWN WIRE-1-LEFT H0120101082A FOLD DOWN WIRE-3-RIGHT H0120101082D FOLD DOWN WIRE-3-LEFT H0120101082E HANDLE BACK H0120201179B...

  • Page 10: Spray Arm Components

    SPRAY ARM COMPONENTS DWG 005199...
  • Page 11 SPRAY ARM COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION WEIR INCL FLOW METER H0120801702A O-RING GASKET WEIR H0120200382 NUT BREATHER RING WEIR H0120200401 HOSE DRAIN (LONG) H0120201665A UPPER SPRAYER ASSY H0120802830 O RING GASKET H0120301022 UPPER SPRAY BASE H0120200906 CLAMP HOSE H012G1040020 H0120301040A HOSE TOP SPRAYER...
  • Page 12 SPRAY ARM COMPONENTS DWG 005199...
  • Page 13 SPRAY ARM COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION CLAMP HOSE 32-50MM H0120105775 PIPE DIVERTER MOTOR PUMP H0120200358 FIRE BLANKET H0030508588J SCREEN SUMP OUTLET H0120200378 SUMP ASSY H0120802652B DRAIN PUMP H0120400050C FRAME NON RETURN VALVE H0120200374 FLAP NON RETURN VALVE H0120200373 SCREW ST3.9 13 H012G801050 CLAMP DRAIN HOSE...

  • Page 14: Base & Flood Components

    BASE & FLOOD COMPONENTS DWG 005219...
  • Page 15 BASE & FLOOD COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION PLATE PLASTIC OVERFLOW H0120802597 PANEL LOWER FRONT H120102027 HOSE OVERFLOW PLATE H0120200635 TRAY BOTTOM BASE H0120100239B FLOAT H0120505219A FLOAT SUPPORT H0120202056C MICRO SWITCH FLOAT SWITCH H012G6050040A VALVE INLET H0120400055F BRACKET LOWER REAR H120102029 BOLT H0020600179...

  • Page 16: Door Components

    DOOR COMPONENTS DWG 005200...
  • Page 17 DOOR COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION PANEL DOOR INTEGRATED GALV H0120100425A KIT SS SIDE STRIP LEFT H0120803973 SS SIDE STRIP LEFT X 1 Includes SCREW X 2 Includes H0077050051 BOX DISPLAY BOARD LEFT H0120201468 UI DISPLAY PCB KIT H0121800104F CONTROL PANEL H128805366 BOX DISPLAY BOARD RIGHT...
  • Page 18 FISHERPAYKEL.COM © Fisher & Paykel Appliances Ltd 2020. All rights reserved. The product specifications in this document apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this document correctly describes the product currently available.
