- Page 1 Dishwasher Installation instructions User guide DW60CE and DW60CC models NZ AU SG...
-
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introduction Using your dishwasher – quick reference CE models Controls and starting a wash CC models Controls and starting a wash Changing the wash programme Setting Delay start Changing the wash zone User preference settings Caring for your dinnerware Loading Water hardness and dishwashing... -
Page 5: Safety And Warnings
Safety and warnings Your dishwasher has been carefully designed to operate safely during normal dishwashing procedures. Please keep the following instructions in mind when you are using your dishwasher. Important safety instructions For your safety, follow basic precautions when using your dishwasher, including the following: Please read all instructions before operating your dishwasher. - Page 6 Safety and warnings Important safety instructions Operational Use the dishwasher only for its intended function as described in this user guide. This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; –...
- Page 7 Safety and warnings Important safety instructions Maintenance Do not repair or replace any part of the dishwasher or attempt any servicing unless specifically recommended in this user guide. We recommend that you call a Fisher & Paykel Authorised Service Agent. Keep the floor around your dishwasher clean and dry to reduce the possibility of slipping.
-
Page 8: Installation Instructions
Installation instructions Before you start Safety and compliance These instructions are intended as a guide only. It is the responsibility of the installer to ensure that installation complies with applicable regulations and local government by-laws. Installation must be performed by a suitably qualified person. Incorrect installation or malfunctioning resulting from incorrect installation are not covered by warranty. -
Page 9: Installation Instructions 7
Installation instructions Technical data Check the electrical data on the rating label (located on the left-hand side of the dishwasher’s stainless steel inner door). Should the data on the rating label be different to those specified below, consider those on the rating label as correct. Capacity 14 standard place settings Mains water pressure... - Page 10 Installation instructions Product and cabinetry dimensions Product dimensions (mm) overall height of product with top panel in place 850 (min) -870 (max)** with top panel removed* 820 (min) -840 (max)** overall width of product overall depth of product depth of open door (measured from front of kickstrip) Cabinetry dimensions (mm)
- Page 11 Installation instructions Preparing the product and cabinetry The top panel may be removed to suit underbench cavity height. See the illustrations below. Important! To prevent possible steam damage to the cabinetry, ensure that any bare wood surrounding the dishwasher is sealed with an oil-based paint or moisture-proof polyurethane.
- Page 12 Installation instructions Levelling and positioning the dishwasher Before sliding the dishwasher into position, adjust the feet with a spanner (1) to ensure that the dishwasher is level (2) and the required height. Do not lift the dishwasher from the door handle or top panel. Position the dishwasher in the cavity, ensuring that the hoses and power cord don’t get bent, crimped, or trapped under the dishwasher in the process (3).
- Page 13 Installation instructions Plumbing -- Waste connection These drainage options are designed to eliminate problems that occur with combined sink-dishwasher waste systems. Drainage option A: Separate sink and dishwasher waste systems The standpipe must have a minimum diameter of 38 mm and stand 750 mm above the floor. Use the supplied drain hose support to hold the drain hose in place in the standpipe.
- Page 14 Installation instructions Plumbing -- Water inlet connection Important! The appliance should be connected to the water main using the new water inlet hose supplied. Old hoses should not be used. Do not shorten the inlet hose. Take note of water connection requirements. The dishwasher has a single valve water connection.
-
Page 15: Electrical Connection
Installation instructions Electrical connection The dishwasher must not be connected to the electrical supply while installation is being carried out. Ensure all domestic wiring is properly earthed. Check the rating label (located on the left-hand side of the dishwasher’s stainless steel inner door) and ensure that the voltage and frequency values for the current in the house correspond to those on the rating label. -
Page 16: Introduction
Introduction Before you start Make sure the installer has completed the ‘Final checklist’ in the Installation instructions. Read this manual thoroughly, taking special note of the ‘Safety and warnings’ section. Remove all the packaging and check that you have all the accessories listed below. Dishwasher features and accessories Utensil tray Upper basket... -
Page 17: Using Your Dishwasher - Quick Reference
Using your dishwasher – quick reference Starting a wash Remove food scraps and load dishes carefully For more detail, see sections ‘Caring for your dinnerware’ ‘Loading’ Add detergent For more detail, see sections ‘Water hardness and dishwashing’ ‘Wash programmes and detergent quantities’ ‘Adding detergent’... -
Page 18: Controls And Starting A Wash
Controls and starting a wash - CE models delay On/Off and Delay Display Heater Rinse aid Keylock start indicator indicator Control panel feature Action to take Turns the power to the dishwasher On/Off Press briefly to turn the on and off. dishwasher on and off. - Page 19 Controls and starting a wash - CE models heavy normal normal fast delicate rinse Programme Programme Start/Pause selector indicators To select and start a wash programme Make sure that the dishwasher is powered on Press until the indicator of the desired programme lights up. Press to start the programme.
- Page 20 Controls and starting a wash - CE models delay On/Off and Delay Display Heater Rinse aid Keylock start indicator indicator To cancel a wash programme once it has started Press to pause the programme. Press to turn the dishwasher off. The programme has now been cancelled.
- Page 21 Controls and starting a wash - CE models heavy normal normal fast delicate rinse Programme Programme Start/Pause selector indicators Delay start This feature can delay the start of a wash programme by 1 to 12 hours. To activate Delay start: Load the dishes, add detergent and close the door.
-
Page 22: Controls And Starting A Wash
Controls and starting a wash - CC models Power/ Start/Pause Scroll Display Keylock Press to start or Press to navigate Shows settings, pause a wash through menus options, wash Press briefly to programme and options programme power on or off status, or press and hold fault codes and... - Page 23 Controls and starting a wash - CC models READY TO WASH Full SETTINGS Heavy NO Delay Select/Confirm Back/Cancel Status indicator Wash Delay Wash User programme Start zone preference Press to select Press to step setting setting settings settings or confirm a back in menu See section See section...
-
Page 24: Changing The Wash Programme
Changing the wash programme - CC models Note: The dishwasher will remember the last programme used. Make sure that the dishwasher is powered on Scroll to highlight the icon of the wash programme last used. READY TO WASH Heavy NO Delay Full SETTINGS Press... -
Page 25: Setting Delay Start
Setting Delay start - CC models This feature can delay the start of a wash programme by 1 to 24 hours. Load the dishes, add detergent and close the door. Press to turn the dishwasher on. Check that the display shows the wash programme you require. If not, see instructions for ‘Changing the wash programme’... -
Page 26: Changing The Wash Zone
Changing the wash zone - CC models If you don’t have a full load and want to save energy and water, you can choose to wash the lower basket or upper basket only. This may be useful if, for example, you only wish to wash the breakfast dishes which are in the upper basket. -
Page 27: User Preference Settings
User preference settings - CC models These allow you to: optimise your dishwasher for the type of adjust screen brightness and contrast detergent you use turn the beeps on or off turn rinse aid on or off reset the dishwasher to original have the temperature displayed in factory settings. -
Page 28: Caring For Your Dinnerware
Caring for your dinnerware The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in the dishwasher. Remember, if in any doubt about any aspect concerning items washed in the dishwasher, follow the instructions from the manufacturer of the items, or wash the item by hand. -
Page 29: Loading
Loading DON’Ts Arrange the dishes neatly, spacing them Don’t overcrowd the dishwasher. This will evenly for maximum exposure to water. reduce performance. Remove any large food particles before Don’t allow plates and cutlery to nest. placing dishes in the dishwasher. This is to Don’t let dishware block water from prevent the filters from becoming clogged. - Page 30 Loading Upper basket and utensil tray Utensil tray The upper basket is designed to hold items like glasses, cups, saucers, plates, small bowls and shallow pans. Use the utensil tray to securely hold long or sharp items like knives, chopsticks, or ladles. Ensure that knife blades are facing down.
- Page 31 Loading Adjusting the height of the upper basket - CC models You can adjust the height of the upper basket even when it is fully loaded, as you do not have to remove it from the dishwasher. To lift the basket, hold it on one side and carefully pull upwards until it clicks into place.
- Page 32 Loading Lower basket Place the largest items here: pots, pans, lids, serving dishes and bowls. Fold down the tines to place pots and pans flat on the bottom. Ensure dishware items do not block the spray arm above from rotating. If you need more height for tall items, you can raise the upper basket.
-
Page 33: Water Hardness And Dishwashing
Water hardness and dishwashing What is water hardness? Hard water is water with a high concentration of minerals such as calcium and magnesium. In soft water, this concentration is low. Water hardness varies by geographical location. How does water hardness affect dishwashing? Hard water can be detrimental to the performance of your dishwasher. -
Page 34: Wash Programmes And Detergent Quantities
Wash programmes and detergent quantities The quantities in the table below are for powdered detergent and typical levels of soiling. If your home has softer or harder water, or to suit the particular load, you may need to adjust these quantities. -
Page 35: Adding Detergent
Adding detergent Important! Only use detergents recommended for automatic dishwashers. Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children and infirm persons away from the dishwasher when it is open. Check that the detergent dispenser is empty after completion of each wash programme. -
Page 36: Using Rinse Aid
Using rinse aid We highly recommend using liquid rinse aid regularly to get the best drying results. Rinse aid gives a streak-free, sparkling clean look to glass and chinaware. In addition, it prevents metal from tarnishing. Rinse aid indicators When to refill the rinse aid dispenser When rinse aid level becomes low, the rinse aid indicators on the dispenser and the control panel will light up to remind you to refill the dispenser. -
Page 37: After The Wash
After the wash When the wash programme is over, the dishwasher will beep six times, then automatically turn off in a few seconds. In CC models, a drying fan will continue to run for about an hour, or until the door is opened. Open the door slightly and leave it ajar (about 100 mm) to help the drying process. -
Page 38: Care And Cleaning
Care and cleaning Over time, food residue or limescale deposits may accumulate inside your dishwasher. These may reduce efficiency, and food residue may produce a bad odour. Inspect and clean your dishwasher regularly. Important ! Before any cleaning or maintenance, always disconnect the dishwasher from the power supply, turn off the water supply, and wait until all parts of the dishwasher have cooled. - Page 39 Care and cleaning Cleaning the filters The filters prevent larger food particles in the wash water from reaching the pump. These particles may occasionally block the filters. We recommend cleaning the filters whenever there is evidence of food particles. Remove the filters, as shown, then rinse them thoroughly under running water. Important ! When cleaning the underside of the filter plate, take care handling its sharp outer edge.
-
Page 40: Fault Codes
Fault codes If the dishwasher malfunctions, it will display a fault code and beep. Check the table below to see if you can correct the fault yourself before contacting Fisher & Paykel Customer Care. If the dishwasher still will not work, or shows any other fault code Press to turn the dishwasher off and wait a few minutes. -
Page 41: Troubleshooting
Troubleshooting Problem Possible cause What to do No power. Ensure the dishwasher is plugged in and the Dishwasher will not power supply is turned on at the wall. start. The door is not properly Close the door. closed. Start/Pause button Press the Start/Pause button not been pressed. - Page 42 Troubleshooting Problem Possible Cause What to do Knocking or rattling Spray arm knocking against Pause the wash and rearrange dishes. See sound during wash. dishes. sections ‘Controls and starting a wash’ and ‘Loading’ . Dishes have been stacked incorrectly. Unclean dishes. Wash programme See section ‘Wash programmes and unsuitable for load.
- Page 43 Troubleshooting Problem Possible cause What to do Dishes, cutlery have Rinse aid dosage too low. Increase rinse aid dosage. See ‘Using rinse not dried. aid’ . Items removed too soon. After the end of the wash programme, leave the door ajar and wait for several minutes to help drying.
-
Page 44: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed you are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &... -
Page 45: Wash Programme Data
Wash programme data CE and CC models Heavy Normal Normal Eco* Fast Delicate Rinse pre-wash pre-wash pre-wash pre-wash pre-wash main wash 70 main wash 55 main wash 46 main wash 40 C main wash 45 post-rinse 1 post-rinse 1 post-rinse post-rinse post-rinse post-rinse 2... -
Page 46: Standards Test
Standards test The dishwasher is tested to AS/NZS 2007 standards for both wash and dry performance using the parameters detailed below. Wash programme Normal Eco When the programme is finished, open the door 100mm to help with drying Powdered detergent quantities 5 g pre-wash + 27.5 g main wash Rinse aid dosage level Maximum number of place settings... - Page 48 www.fi sherpaykel.co.nz www.fi sherpaykel.com.au www.fi sherpaykel.com.sg Copyright © Fisher & Paykel 2012. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
