- Page 1 NARAK 460 Instruction book...
- Page 2 • Get the parts out of the bag on a flat surface Your bags contain : 1- front half frame. 2- front half frame extension. 3- skin. 4- half centre crossrib. 5- cockpit rim. 6- seat (expedition model). 7- rear half frame extension. 8- faisceau AR •...
- Page 3 • Turn the first crossrib 90° (below) and secure its position with the little straps. • Do the same for the second crossrib.
- Page 4 • Take the front half frame extension (red marks) and connect it to the front half frame. • Take the keel bar and insert it with a few degrees of angle (besides). Once in place a metal stopper holds the two pieces in place (below).
- Page 5 • Connect the deck top stringers and turn the metal locker to block them together. • Put the pin to hold in place • Put in place crossrib n°3. the starboard deck stringer. Important notice : leave crossrib n°4 free (besides) otherwise you will not be able to bend the stringers and gunwhales once the frame in the skin...
- Page 6 • Get the front half frame in the skin. • Put a leg avor the boat, it helps • The frame have to be centered to have the frame centered in in the skin. A bolt will go through the skin. the eyelet and the hole in the top stringer.
- Page 7 • Be sure hoses from the stabilairs and the rudder lines are not struck under the frame parts. • Apply tension to the keel bar. put • Push the lever down to make the keel into the lever. the tension. Turn the locker 90° to secure the lever (below).
- Page 8 • Take the gunwales in both hands and push them to the center of the boat, plying the gunwales • Release the gunwhales once connected. Do the same for the stringers (below). • Turn the two remaining crossribs in place. Take car of the position of the gunwhale on the crossrib (below left).
- Page 9 • At the front of the cockpit push the two deck stringers to the sides. • You will now put in place the central half crossrib. • Put it under the gunwales. • Pull the locker and connect it • Put the pin on each side of the to the screw head on the keel.
- Page 10 • Get the cockpit rim on the skin. The bolts (in the inside pocket of the skin bag) go through the skin and the top stringer. Screw the butterfly nut. • Get the hem of the skin into the cockpit rim gauge.
- Page 11 • Disassembly of the kayak : do the other way round. Deflate the stabilairs. Unscrew the cockpit rim. Get the half center crossrib off. Turn the two crossribs at the cockpit ends free. Release the central tension, pulling on the lever. Grab the gunwhales and dis- connect them.
- Page 12 Parc des Coëvrons ouest 53480 VAIGES Tél. : 02 43 90 20 26 info@nautiraid.com...
