Sentinel™ EFI-MFZ-50
User's Manual
be specified at time of order. The flexible sensor core is mounted on the screened part of
the cable, below the stripback point. The core is wrapped around the cable and the cable-
tie is pulled tight as far as it will go. A second cable-tie is used to hold the core firmly onto
the cable. The cable screen is turned back underneath the core and then terminated to
earth as shown in the Figure 1.
Version 3.0
Page 5 of 15
