Installation

Front
Fold
Side
Fold
1.Drill the holes on the door according
to the template;
4.Install the front panel on the door,
connect the cable with the mortise
cable;
7.Connect the power cable with the
battery case
2. Install the mortise into the door,
and fasten the screws;
5.Insert the spindle and the deadbolt
spindle into another side of the
mortise
8.Try to unlock the lock and confirm
the installation is correct.
2
3.Install the cylinder into the mortise,
and then install the cover on the
mortise. Insert the spindle into the
mortise.
6.Install the back panel on the door,
and fasten the screws
