Installation
Drill the holes on the door and then
a
install the mortise into the door;
c
Install the front panel on the door
Install the back panel on the other
e
side of door, and then fasten both
panels and install the batteries.
b
Install the spindle into the handle hole
in the front panel, and then insert the
rod and fasten it;
d
Connect the cable between the front
and back panels
Test the installation to confirm the
f
installation is successful.
1
