- Page 1 Alpha Murphy Bed Assembly Instructions Questions call 501.753.9699 Designed to exceed International ISO 9002 Standards for Residential Specifications...
-
Page 2: Table Of Contents
Table Of Contents Unpacking Your Bed Tools Needed Step 1: Assemble the Bed Cabinet Step 2 Light Option Step 3: Attach Bed Cabinet Securely to Wall Step 4: Install the Bed Face Panel Unit Step 5: Install Handle = Legs - Mechanism Covers - Mattress Step 6 Plug in the Lights: Follow up to Initial Assembly Additional Options... -
Page 3: Unpacking Your Bed
Unpacking Your Bed Remove all boxing, foam, and shrink wrap and make sure all components are there. Each customer piece will vary but in general you should have: Do not throw away packaging until you are complete ( smaller items could be lost in packaging) ●... -
Page 4: Step 1: Assemble The Bed Cabinet
Step 1: Assemble the Bed Cabinet ● If possible, the Bed Cabinet should be assembled in the room where it will be used. ● Be sure Lift Mechanisms are securely installed. 1-1: Headboard installation Insert the headboard dowels into the ends of the headboard (two on each side). No need to measure we’ve taken that step out of you. -
Page 5: Step 2 Light Option
Step 2 Light Option If you don’t have lights skip to step 3. 2-1. Connect the large control box to headboard. Screw the large control box to the back side of the headboard with 1 ½” screws. Attach it about center and toward the bottom of the headboard. -
Page 6: Step 3: Attach Bed Cabinet Securely To Wall
Step 3: Attach Bed Cabinet Securely to Wall We cut out for your base molding so you don’t have to remove base molding off your wall. If our cutout was not large enough an additional cut may need to be done. Our cutout should accommodate a 5” high base. Use a jig saw to perform this task. - Page 7 3-3 Lock the arm into place Holding one foot against the bottom front edge of the side panel and using the 13” (330mm) PVC tube, lever the tension arm out until you can set the arm lock to the hex nut at the hole A (see drawing 13.). This is the hex nut at the top front corner of the mechanism.
-
Page 8: Step 4: Install The Bed Face Panel Unit
Step 4: Install the Bed Face Panel Unit 4-1: We have Inserted a Allen Head Bolts through Hole #1 (6 3/4” from end of side frame) on both left and right side frames (see Drawing 14). 4-2 We have also Inserted two 5/16“ (M8x20mm) Hex Head Bolts from the outside of the frame through Hole #3. -
Page 9: Step 5: Install Handle = Legs - Mechanism Covers - Mattress
Step 5: Install Handle = Legs - Mechanism Covers - Mattress 5-1 Pre-Drilled Holes for Handle On most application we have drilled the holes for the handle. Position and secure handles for ease of operation. 5-2 Customer Drills for Handles If you are installing your own handles, measure down approximately 36”... -
Page 10: Step 6 Plug In The Lights
Step 6 Plug in the Lights: Mount the small control box to the back of the “Frame and face Panel”. Remove the tape backing and stick the control box to the back of the metal frame. M ake sure the arrow is facing up and toward the wall . Complete Bed Assembly Follow up to Initial Assembly Check that the Bed Cabinet is level and square so the Bed Face has equal clearance of the Cabinet on both... -
Page 11: Additional Options
Additional Options Bookcase Option The bookcase will mount to the bed at the top using 1 ¼” screws. You can also put one inside the lower section by pulling out a drawer. We may not have pre-drill for these holes so you can place them anywhere. -
Page 12: Desk Option
Desk Option Note: We have put the screws back in on the face (right above the black bracket) and also at the bottom. Remove those screws and use them to assemble the desk Desk Step D-1 | Attach the Desk Riser to the Desktop. If they are not already inserted, insert the hardwood dowels into the bottom of the Desk Riser. - Page 13 Notes:...
