- Page 1 Alpha Murphy Bed Assembly Instructions Face Assembled Questions call 501.753.9699 Designed to exceed International ISO 9002 Standards for Residential Specifications Revised 3/31/2021...
-
Page 2: Table Of Contents
Table Of Contents Unpacking Your Bed Videos Installing The Springs Mounting Lift Mechanism Assemble the Bed Cabinet Attach Bed Cabinet Securely to Wall Install the Bed Face Panel Unit Install Legs Mounting the Face Plug in the Lights: Follow up to Initial Assembly Additional Options Bookcase Option Desk Option... -
Page 3: Unpacking Your Bed
Unpacking Your Bed Remove all boxing, foam, and shrink wrap and make sure all components are there. Each customer piece will vary but in general you should have: Do not throw away packaging until you are complete (smaller items could be lost in packaging) Parts Provided Tool Needed ❏... -
Page 4: Installing The Springs
Installing The Springs Video: Adding Springs NOTE: Some models may have the correct number of springs already installed. Check the chart and if your bed already has them installed then skip this section. 1-1. The Number of springs in the Lift Mechanism will vary by size and application of the Murphy Bed. Check chart below. -
Page 5: Mounting Lift Mechanism
Mounting Lift Mechanism Video: Mounting the Lift Mechanism NOTE: Some models may have the Lift Mechanism already mounted to the verticals. If this is the case with your Murphy bed then you can skip this section. 2-1. The left and right Lift Mechanism hole pattern will line up with the hole pattern on the Side Panels (B). - Page 6 3-2. Lay the verticals on the floor with the mechanism facing up and the head of the bed toward the wall. 3-3. Place the dowels in the end of the headboard into the dowel holes in the vertical making sure the headboard screw pockets are facing toward the back and the finished edge of the headboard is facing what would be up (when lying on the floor, finished edge will be away from the wall) 3-4.
- Page 7 Figure L-1b (Outset Lights) L-1 Mount control box to the back of the headboard using 2” screws. Mount this centered and toward the bottom of the headboard. L-2. Mount the Touch Plate to the top/back of the headboard, centered, using a ¾” screw. Note: drawing shows a knob instead of a plate.
- Page 8 NOTE: Some pre-installed models may already have the cord installed in the groove. L-6. Plug the other side (top side) of the extension cord into the lights. L-7. Plug the control box that you connected to the headboard into into a wall outlet. Test the lights. With the outset lights the, lights should come on when the touch plate is touched on the headboard.
- Page 9 BACK TO REGULAR INSTRUCTIONS Video: Cabinet part 2 Stand the unit up and into its approximate place in the room. Check that the cutout made to clear your base molding is sufficient. If not make the height it needs to be. Lay the unit back down on the face, and adjust the cutout.
-
Page 10: Attach Bed Cabinet Securely To Wall
Attach Bed Cabinet Securely to Wall Video: Attaching to wall 4-1: Find Studs Prior to placing the cabinet against the wall, locate 3-4 studs on queen size (4-5 on King) or other wall frame members at the level of the Top Panel (top of bed). Alert: The cabinet must be secured to studs or other wall structural members or injury and damage could occur. -
Page 11: Install The Bed Face Panel Unit
Install the Bed Face Panel Unit Lock the arm into place Videos: Locking Spring Frame Bolts and Straps Caution: If possible have a helper assist in the setting of the mechanism and loading of the bed face panel. DO NOT reach behind the tension arm when you are doing the setting procedure. To avoid reaching behind the Tension Arm, use a pencil or screw driver to move the Arm Lock into place. -
Page 12: Install Legs
Install Legs Video: Legs 7-1 Install legs with the washers on the inside of the Rails and the Nylon washer on the outside. Tighten nut to have a small amount of friction when leg assembly is rotated from the up to the down position. 7-2 Install leg connector rod between legs and secure with 1/4”x1 1/4”... -
Page 13: Mounting The Face
Mounting the Face Video: Mounting the Face NOTE: Two people are needed for this step. 6-1. Lift the unit vertically to a height where the bolts in holes #3 are several inches above the top of the Tension Arms. Gently fit the unit between the arms, tilt it back approximately 10 degrees so that the head end of the until clears the Bottom Kick, then lower it so that the #3 bolts slide into the slots at the end of the Arms. -
Page 14: Plug In The Lights
Plug in the Lights: Mount the small control box to the back of the “Frame and face Panel”. Remove the tape backing and stick the control box to the back of the metal frame. Make sure the arrow is facing up and toward the wall. Complete Bed Assembly Follow up to Initial Assembly Video:... -
Page 15: Additional Options
Additional Options Bookcase Option The bookcase will mount to the bed at the top using 1 ¼” screws. You can also put one inside the lower section by pulling out a drawer. We may not have pre-drilled for these holes so you can place them anywhere. Desk Option Note: On some applications we have put the screws back in on the face (right above the Desk Bracket) and also at the... -
Page 16: Desk Step D-3 | Place Desk Hinge Into Hinge Clip
Desk Step D-3 | Place Desk Hinge into Hinge Clip NOTE: Two people are needed for this step With the Desk rotated 90° up, place the loose end of the hinge into the Hinge Clip and secure with ⅝” flat-head screws. Desk Step D-4 | Reattach Base Rotate the desk back down and re-insert the ⅝”...
