- Page 1 Alpha Murphy Bed Assembly Instructions Face Unassembled Questions call 501.753.9699 Designed to exceed International ISO 9002 Standards for Residential Specifications Revised 12/14/2019...
-
Page 2: Table Of Contents
Table Of Contents Unpacking Your Bed Videos Installing The Springs Mounting Lift Mechanism Assemble the Bed Cabinet Attach Bed Cabinet Securely to Wall Assemble the Face Install Legs Install the Bed Face Panel Unit Frame Bolts and Straps Mounting the Legs Mounting the Face Plug in the Lights: Follow up to Initial Assembly... -
Page 3: Unpacking Your Bed
Unpacking Your Bed Remove all boxing, foam, and shrink wrap and make sure all components are there. Each customer piece will vary but in general you should have: Do not throw away packaging until you are complete ( smaller items could be lost in packaging) Parts Provided Tool Needed ❏... -
Page 4: Installing The Springs
Installing The Springs Video: A dding Springs NOTE: Some models may have the correct number of springs already installed. Check the chart and if your bed already has them installed then skip this section. 1-1. The Number of springs in the Lift Mechanism will vary by size and application of the Murphy Bed. Check chart below. -
Page 5: Mounting Lift Mechanism
Mounting Lift Mechanism Video: M ounting the Lift Mechanism NOTE: Some models may have the Lift Mechanism already mounted to the verticals. If this is the case with your Murphy bed than you can skip this section. 2-1. The left and right Lift Mechanism hole pattern will line up with the hole pattern on the Side Panels (B). - Page 6 3-2. Lay the verticals in the floor with the mechanism facing up and the foot of the bed toward the wall. 3-3. Place the dowels in the end of the headboard into the dowel holes in the vertical making sure the headboard screw pockets are facing toward the back and the finished edge of the headboard is facing what would be up (with lying on the floor finish edge will be away from the wall) 3-4.
- Page 7 STOP IF YOU HAVE LIGHTS Video: L ights If you have lights, you will want to make sure your wiring and control box is in place. L-1 Mount control box to the back of the headboard using 1-½” screws. Mount this centered and toward the bottom of the headboard.
- Page 8 BACK TO REGULAR INSTRUCTIONS Video: C abinet part 2 Stand the unit up and into its approximate place in the room. Check that the cutout made to clear your base molding is sufficient. If not make the height it needs to be. Lay the unit back down on the face, and adjust the cutout.
-
Page 9: Attach Bed Cabinet Securely To Wall
Attach Bed Cabinet Securely to Wall Video: A ttaching to wall 4-1: Find Studs Prior to placing cabinet against the wall, locate 3 studs (you may only find 2 on a twin size) or other wall frame members at the level of the Top Panel (top of bed). Alert: The cabinet must be secured to studs or other wall structural members or injury and damage could occur. -
Page 10: Assemble The Face
Assemble the Face Lock the arm into place Videos: L ocking Spring a nd F rame Bolts and Straps Caution: If possible have a helper assist in the setting of the mechanism and loading of the bed face panel. DO NOT reach behind the tension arm when you are doing the setting procedure. -
Page 11: Install The Bed Face Panel Unit
Install the Bed Face Panel Unit Video: F ace Part 1... - Page 13 F-1 Lay the Bed Face Panels down on a non-scratch surface such as a carpet or blanket. Make sure they the better side is face down and banded edges facing out and toward the foot of the bed. The foot of the bed will be away from the assembled cabinet.
-
Page 14: Frame Bolts And Straps
Frame Bolts and Straps Three holes used in the frame starting at the head end. Hole 1. Starting with Hole #1 inset the Alen Head bolt and secure it with a Nylock Nut on the inside. Use the Allen wrench provided and a ½” wrench or socket to tighten. -
Page 15: Mounting The Face
L-5 Attach the connector bar to the legs using the 1-¼ bolts and star washer. See diagram. L-6 Feed the 1 ¼” bolt with the star washer thought the hole in the leg and into the Steel Leg Rod. Tighten with a 7/16” wrench or socket. -
Page 16: Plug In The Lights
Caution: Hold the Face Panel securely, Do Not let it slam shut. Balance is not achieved until the mattress is loaded in the bed and will not stay down. Holding the upper edge of the Bed Panel Unit, gently let the bed closed. If all is well, you should have even clearance between the side edges of the panel unit and the insides of the Side Panels. -
Page 17: Additional Options
Additional Options Bookcase Option The bookcase will mount to the bed at the top using 1 ¼” screws. You can also put one inside the lower section by pulling out a drawer. We may not have pre-drill for these holes so you can place them anywhere. Desk Option Note: On some applications we have put the screws back in on the face (right above the black bracket) and also at the... -
Page 18: Desk Step D-3 | Place Desk Hinge Into Hinge Clip
Desk Step D-3 | Place Desk Hinge into Hinge Clip With the Dask rotated 90° up, place to loose end of the hinge into the Hinge Clip and secure with ⅝” flat-head screws. Desk Step D-4 | Reattach Base Rotate the desk back down and re-insert the ⅝” pan-head screws that were removed from Step D-1.
