TLW STRATA Installation Manual

Product Name: STRATA Stainless Steel Square Plinth Light 0.18W
Product Code: K01-0040

Kit Contents

Plinth light with 2m cable c/w micro plug
▪

Important Safety Information

Please read these instructions carefully before attempting to install this product.
It is advisable to keep these instructions in a safe place for further reference.
We recommend that you consult a qualified electrician.
All electrical installations must be carried out in accordance with current regulations and applicable
ordinances.
These products must not be modified. If any modifications are made, it may invalidate the warranty and may
render the product unsafe.
These LED lights operate low voltage (12V).
Do not wire the individual LED light fittings directly to the mains.
This product is for indoor use only.
Keep out of moisture and use only in dry rooms.
Before commencing installation or maintenance, isolate the main electrical supply for the appropriate circuit
at the fuse board.
This product is only suitable for connecting to a 12V supply. The light should be mounted onto a secure
surface. Position lights where they will not be exposed to steam or splashes etc.
Never exceed the total output of the LED drier.
Suitable for furniture lighting
When the lamp expires the fitting must be replaced.
Class III safety extra low voltage (SELV)

Installation

1
Cut out 45mm for plinth light
2 Each light is fitted with a 2m cable c/w
micro plug. Plug the micro plug into
the driver's connector block (driver
may not be supplied with lights)
