Product Name: Slim Rectangle LED Panel Light 6W
Product Code: K01-0191
Kit Contents
LED cabinet light with micro connector
▪
Important Safety Information
Installation should only be carried out by a qualified electrician.
Do NOT connect directly to the mains supply.
Installation
1
Create a 8mm diameter hole for the
connector cable to reach the LED
driver.
3
Peel the 3M VHB sticker.
5
Connect driver to 240V power supply
(driver may not be supplied with lights)
Thread the connector through a
2
hole to the LED driver.
4
Stick the LED light onto the board.
Advertisement
Table of Contents
Related Manuals for TLW vew K01-0191
Summary of Contents for TLW vew K01-0191
- Page 1 Product Name: Slim Rectangle LED Panel Light 6W Product Code: K01-0191 Kit Contents LED cabinet light with micro connector ▪ Important Safety Information Installation should only be carried out by a qualified electrician. Do NOT connect directly to the mains supply. Installation Thread the connector through a Create a 8mm diameter hole for the...
- Page 2 Product Name: Slim Rectangle LED Panel Light 6W Product Code: K01-0191 Other Information Specification: Size: 200x100x5.3mm Work voltage: DC12V Power: 6W Colour: White Lighting colour: Warm White/ Natural White Installation: Using 3M VHB sticker Material: Aluminium alloy +light guide plate Application: Kitchen, closet, shelf Advantage: Save energy, longevity, non-flicker Main adapter wiring diagram:-...
