The ALDI WORK ZONE ASP12-ES may not be sucking due to several possible reasons:

1. Filter Issue – The vacuum must not be used without the filter. A clogged or improperly installed filter could reduce suction.
2. Blockage – The suction hose, container, or nozzle might be blocked. Check and clear any obstructions.
3. Assembly Problem – Ensure the vacuum is correctly and completely assembled.
4. Power Issue – Verify that the vacuum is properly connected to a power source and turned on.
5. Damaged Parts – Worn-out or damaged hoses, seals, or accessories may affect suction.
6. Overfilled Container – If the container is full, empty it to restore suction.

If the issue persists, refer to the troubleshooting section of the manual or contact after-sales support.

This answer is automatically generated

Summary of Contents for ALDI WORK ZONE ASP12-ES

Page 1: Table Of Contents
If you are not entirely satisfied with this Assembly product, please return it to your nearest ALDI store within 60 days from Operation the date of purchase for a full refund or replacement, or take advantage of our after sales support by calling the supplier’s Customer Service Hotline.
Page 2: Overview
Overview Utilisation Pack contents/parts ASP12-ES Contents of Box Wet & Dry Vacuum cleaner Castors Screws Suction hose Foamed plastic filter Paper bag Additional filter Adapter Crevice nozzle 3-part suction tube Floor nozzle Instruction manual Warranty certificate AFTER SALES SUPPORT  support@scheppach.com.au ...
Page 3 ASP12-ES AFTER SALES SUPPORT 1300 855 831  support@scheppach.com.au  MODEL: ASP12-ES PRODUCT CODE: 62361 10/2018...
Page 4: Explanation Of Symbols
Explanation of symbols ASP12-ES Explanation of Symbols Read the operating instructions to reduce the risk of injury. Class II symbol: This high pressure cleaner is designed with dual insulation and does not need to be connected to an earthed power socket. Compliance with the Australian requirements.
Page 5: Introduction
Introduction ASP12-ES I. Introduction Congratulations on choosing to buy a WORKZONE product. ® All products brought to you by WORKZONE are manufactured to the highest ® standards of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will enjoy using your purchase for many years to come.
Page 6: Layout
Introduction/Layout/Scope of delivery ASP12-ES In addition to the safety notes contained in the present operating instructions and the special regulations of your country, the generally recognised technical rules for the operation of this appliance must be observed. II. Layout (Fig. 1.1, 1.2, 1.3) Handle On/Off switch Appliance head...
Page 7: Intended Use
ASP12-ES Scope of delivery/Intended use/Safety regulations Warranty Certificate (1x) Manual (1x) • Open the packaging and take out the appliance carefully. • Remove the packaging material as well as the packaging and transport bracing (if available). • Check that the delivery is complete. •...
Page 8 Safety regulations ASP12-ES • Never leave a machine which is ready for operation unattended at the workplace. • People and animals must not be vacuumed with the machine. • Do not vacuum any hot, incandescent, flammable, explosive materials, or those which endanger health.
Page 9: Technical Data
ASP12-ES Safety regulations/Technical data breaker (RCD) with a rated leakage current of not more than 30 mA. • Do not expose the unit to rain CAUTION! The following states how damage to the appliance and possible injury to people can be avoided: •...
Page 10: Assembly
Assembly ASP12-ES VII. Assembly m Warning! Ensure the appliance is correctly and completely assembled before use. Unpacking (Fig.1.1) Unlock the locking hooks (8) and remove the appliance head (3). Remove all accessories from the container (7). Mounting of the castors (Fig.2) Place the container (7) upturned on the ground.
Page 11: Operation
ASP12-ES Assembly/Operation Fitting the suction hose (Fig. 7) Connect the suction hose (11) to the corresponding connector on the wet and dry vacuum cleaner, depending on the application required. Vacuuming: Connect the suction hose (11) to the suction hose connector (4). Blowing: Connect the suction hose (11) to the blow connector (10).
Page 12: Maintenance And Cleaning
Operation/Maintenance and cleaning ASP12-ES Wet vacuuming (Fig. 1.3) For wet-vacuuming, use the foamed plastic filter (12). Ensure that the foamed plastic filter (12) is correctly mounted. When wet vacuuming, the safety float valve close if the maximum level is reached. The motor is still running, but the suction function is not workable anymore.
Page 13: Troubleshooting
ASP12-ES Maintenance and cleaning/Troubleshooting Cleaning It is recommended to clean the appliance after each use. Never direct a water jet against the appliance, nor clean the appliance under flowing water. This could give rise to the danger of electric shock and damage the appliance! Always keep the appliance clean.
Page 14: Storage
Storage/Disposal and recycling ASP12-ES XI. Storage • Clean up the appliance before storing. • Drain all the water from the appliance before storing. • Ensure that children cannot reach the appliance. • Store the appliance and its accessories in a frost-free room. •...
Page 15: Warranty Details
WET & DRY VACUUM CLEANER Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.
Page 16 ASP12-ES AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: ASP12-ES PRODUCT CODE: 62361 10/2018...
Page 17: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.
Page 18 ASP12-ES AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: ASP12-ES PRODUCT CODE: 62361 10/2018...
