LINE THERMAL PRINTER
MODEL CT-S2000L/CT-S2000DCL
Refer to CT-S2000/CT-S2000DC User's Manual of standard model when reading this manual.
Contents
1.1 Features
4.6 Error Indications
5.3

Manual Setting of Memory Switch

5.4

Selecting Paper Type

5.5 Adjusting the Sensitivity of Paper Sensor
5.6 Printing Paper
CITIZEN is a registered trade mark of Citizen Holdings Co., Japan
CITIZEN es una marca registrada de Citizen Holdings Co., Japón
Company names and product names in this manual are trademarks or
registered trademarks of relevant companies.
Copyright c 2007 by
CITIZEN SYSTEMS JAPAN CO., LTD.

1.1 Features

High-speed printing at a maximum of 220 mm/s is possible (* 154 mm/s at standard
density on label paper).
Usable with label paper of 57.5 mm, 59.5 mm, and 79.5 mm wide other than 82.5
mm wide.
Automatic adjustment of paper sensor sensitivity is available.
User's Manual

4.6 Error Indication

The following LED indications are added to CT-S2000L/CT-S2000DCL.
Status POWER LED
Wait for cutting label OFF
Paper detection error OFF
5.3 Manual Setting of Memory Switch
Functions of memory switches SW4-1, SW4-2, SW4-4, SW4-5 and SW4-6 of CT-S2000L/
CT-S2000DCL are as shown below. (The
Memory Switch Function
SW4-1 Paper Length Setting
SW4-2 Top of Form at Power ON
SW4-4 Paper Select
SW4-5 Position Detect
SW4-6 Paper Change
* When printing on label paper, adjust the layout so that right and left margins
are 4 mm or more.
* The memory switch SW4-8 will be ignored for black mark paper.
* The memory switches SW2-8 and SW4-8 will be ignored for label.
5.4 Selecting Paper Type
Paper type selection is available by the combination of memory switches SW4-4 and
SW4-5 by the used of "Memory Switch Select Mode". In addtion, the following
procedure is available.
1 Enter Selecting Paper Type mode.
1)Open the printer cover and remove paper. Pressing and holding the FEED button,
turn the printer power ON. The POWER LED starts blinking.
2)Release the FEED button and then close the printer cover. Buzzer sounds and
the paper type currently set is indicated by the LED on the operation panel.
ERROR LED Buzzer
white-on-black characters are factory setting.)
0 (OFF) 1 (ON)
Auto Measure Command
Invalid Valid
Thermal Roll BM.P/Lbl.P *
Black Mark Label
Invalid Valid
