72"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Shaker Collection
3-Door Wardrobe
REV - 06/2021
Assembly Instructions
59 ½"
support@grainwoodfurniture.com
Made in Brazil
21 ½"
2-person assembly
Model #
Finish
SH0901
Cherry
Expresso
SH0902
Walnut
SH0904
PH #2
page 1/18
Advertisement
Related Manuals for GrainWood Shaker SH0901
Summary of Contents for GrainWood Shaker SH0901
- Page 1 Assembly Instructions 21 ½” 59 ½” 2-person assembly PH #2 72” Model # Finish SH0901 Cherry Expresso SH0902 Walnut SH0904 Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com Shaker Collection...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST 44 + 2 4,0x30 8 + 1 45 + 2 3,5x14 10x10 55 + 2 3,5x16 9 + 1 Pz04 4,0x40 4 + 1 4,0x25 7 + 1 ANTI-TIPPING RESTRAINT KIT M4x25 20 + 1 2 + 1 6,0x10 57 + 2 3,0x20... - Page 4 BOX A - 1 of 2 BOX B - 2 of 2 Part # Description Qty. Part # Description Qty. Rear crosspiece Right side Drawer front Left side Drawer right side Upper crosspiece Drawer left side Lower crosspiece Drawer bottom Back panel Drawer back Drawer bottom support...
- Page 5 Tip : Use a hammer in case dowels are hard to install by hand. 8,0x25 ATTENTION PLEASE! click! Attach hinge ( F10 ) to hinge plate if it comes separated. Push hinge against plate until it clicks. page 5/18...
- Page 6 LEFT 3,5x14 Side RIGHT 3,5x16 450mm - 17 3/4" Side 6,0x10 450mm - 17 3/4" Attention: There are no predrilled holes for the A1 screws on part 22. 4,0x30 page 6/18...
- Page 7 Attention: There are no predrilled holes for the A1 screws on parts 03 and 22. 4,0x30 Attention: There are no predrilled holes for the A1 screws on parts 03 and 22. 4,0x30 page 7/18...
- Page 8 Attention: There are no Attention: There are predrilled holes for the no predrilled holes A1 screws on parts 02 for the A18 screws and 22. on parts 02 and 03. 4,0x30 4,0x25 Attention: There are no predrilled holes for the A18 screws on part 04.
- Page 9 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü ü 10x10 û ü 10x10 page 9/18...
- Page 10 G1 G1 10x10 10x10 page 10/18...
- Page 11 Attention: There are no predrilled holes for the A9 screws on parts 06, 07 and 25. A9 A9 27 1/2” A9 A9 3,5x16 Choose the desired shelf height and insert metal supports. metal page 11/18...
- Page 12 Attention: There are no predrilled holes for the A4 screws on parts 02 and 22. 3,5x14 3,5x16 Attention: There are no predrilled holes for the M4x25 A9 screws on part 21. page 12/18...
- Page 13 Attention: There are no predrilled holes for the A9 screws on part 18. 3,5x16 M4x25 page 13/18...
- Page 14 Attention: There are no predrilled holes for the A9 screws on part 18. 3,5x16 M4x25 page 14/18...
- Page 15 page 15/18...
- Page 16 Attention: There are no predrilled holes for the A1 screws on part 08. 1" 4,0x30 page 16/18...
- Page 17 Flip the assembled drawer upside down to install glides. 6,0x10 Drawer Drawer LEFT RIGHT 450mm - 17 3/4" 450mm - 17 3/4" M4x25 Place the labeled drawer on the top position. page 17/18...
- Page 18 ANTI-TIPPING RESTRAINT KIT Install against the furniture on the wall Anchors and screws are not included, choose best type based on your wall Install both parts F8 3,0x20 Tighten them together using the safety strap page 18/18...
