Belmont Garden Rustique Bird Feeder & Bath Owner's Manual

CONTENTS:
Bird Feeder
BIRD FEEDER FOUNTAIN DIAGRAM:
S Hook
Handle
Dancing Water
Attachment
Water Level: Fill
Until Water
Covers Water
Pump
Bird Feeder
Fountain Body
Bird Seed
Compartment
Perches X 2
Battery
Compartment
Control Switches
(NOTE: Use a small trowel to scoop bird seed into Bird Seed Compartment.)
INSERTING & CHANGING BATTERIES (4D CELL BATTERIES NOT INCLUDED):
1. Drain water if necessary. Ensure fountain is not running and turn the Bird Feeder upside down for access to the battery compartment.
2. Turn battery housing counter clockwise and lift out battery assembly (Figure 1). Please note location of notch in the housing and battery cable retaining clip (Figure 1a).
3. Turn the Bird Feeder right side up and set battery compartment next to Bird Feeder housing (Figure 2).
4. Unscrew the battery retaining screws and lift out batteries paying attentiion to battery positions (Figure 2a).
5. Insert 2 batteries with the (+) side facing up and 2 batteries with the (-) facing down (Figure 2b).
6. Re-Install the battery retaining screws (Figure 2a).
7. Re-insert the battery assembly into the Bird Feeder and turn clockwise (Figure 3). Be sure to align notch in the housing and battery cable retaining clip (Figure 1a).
S Hook
Dancing Water
Attachments
2x Perches
INSTRUCTIONS:
1. Place Bird Feeder on a flat, level surface. Clip the S Hook to the handle.
Battery Cover
2. Slide the Perches (2) into the holes on each side of the Bird Feeder, make sure handle is fully upright. Slide in until the perch snaps into place.
3. Fill bowl with water, the water level should just cover the water pump housing. (See fountain diagram). Fill Bird Seed compartment with seed.
NOTE: Use a small trowel to scoop bird seed into Bird Seed Compartment.
4. Turn on your new Belmont Garden
OPERATING YOUR BIRD FEEDER FOUNTAIN:
Retaining Screws
Note: The switches are located on the bottom of the Bird Feeder Fountain (see fountain diagram).
1. Switch Position On: Turns the fountain on and fountain runs until fountain is manually turned off. Unless fountain is turned off, it will run until the
batteries are exhausted.
2. Switch Position Off: Turns Fountain Off
3. Switch Position Auto: Runs the fountain automatically in conjunction with the 1-4 hour timer switch. In position 1, runs for 1 hour with automatic
shut off, turns on again daily at the same time. In position 2, runs for 2 hours with automatic shut off, turns on again daily at the same time. In
position 3, runs for 3 hours with automatic shut off, turns on again daily at the same time. In position 4, runs for 4 hours with automatic shut off,
turns on again daily at the same time.
Power On/OFF 1-4 Hour
Auto Timer
Rustique Bird Feeder & Bath
Figure 1a
Figure 1
Fountain and enjoy.
TM
Need Help?
Call us for assistance at:
1+ (619) 449-2392
or you can email us at:
customercare@belmont.garden
Our Customer Care Department is available:
Monday - Friday 8:30am to 4:00pm PST
11:30am - 7:00pm EST
Perch Installation
O W N E R S M A N U A L
Figure 2a
1.5VX4
Figure 2b
Figure 2 Figure 3
Dancing Water
Attachment (OPTIONAL):
When fountain is not running, connect
the Dancing Water Attachment to the
outlet in the middle of the Bird Feeder Bowl.
