Summary of Contents for Belmont Garden Lorraine Fountain
- Page 2 This product comes with a one year limited warranty against materials and workmanship. Please review the list of accessories included with your Belmont Garden™ Fountain on the next page. Please note, images of parts are not to scale with one another.
-
Page 3: Table Of Contents
CONTENTS Step1: Pedestal & Base Bowl Locking System Step 2: Fountain Bowl Installation Large Bowl Locking System Step 3: Water Pump & Fountain Tier Installation Water Pump Installation Fountain Tier Installation Step 4: Setting Up Your Fountain Fill Your Fountain Operating Your Fountain Troubleshooting and Maintenance Cleaning your Fountain... - Page 4 Parts for your Belmont Garden Fountain: ™ Large Bowl Topper Power Cords & Plugs Base Leveling Shim Pedestal...
-
Page 5: Step1: Pedestal & Base
Step 1: Step 1: Pedestal & Base You will need: Pedestal Base Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 6: Bowl Locking System
Pedestal, Base & Bowl Locking System A look at how the base & bowl locking system works on your Fountain. Top of the Pedestal Bottom of the Base Note: You will notice that there are threads on the top of the Pedestal and there are corresponding threads in the top of the Base. - Page 7 STOP! At this point, your fountain should look like the image below. Go to the next page for the next step to setup your new Belmont Garden™ Fountain. Remember if you need help contact Customer Care: 1+ (619) 449-2392...
-
Page 8: Step 2: Fountain Bowl Installation
Step 1: Step 2: Fountain Bowl Installation You will need: Large Bowl Assembled Base & Bottom Base Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 9: Large Bowl Locking System
Large Bowl Locking System A look at how the Large Bowl locking system works on your Fountain. Bottom of the Large Bowl Top of the Base Note: The same as with the Pedestal and bottom of the Base, you will notice that there are threads on the top of the Base and there are corresponding threads in the bottom of the Bowl. -
Page 10: Step 3: Water Pump & Fountain Tier Installation
Step 1: Step 3: Water Pump & Fountain Tier Installation You will need: Power Cords & Plugs Assembled Base & Large Bowl Fountain Tier Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 11: Water Pump Installation
Water Pump Installation Step 1: Feed the Water Pump cord down the For the next step, you will install the fountain tier pipe. into the large bowl. Rest the fountain tier on the side of the large bowl. Step 2: Route the Electrical Power Cord through Be sure to leave approximately 7 to 8 inches of the base of the fountain and through the notch on slack in the cord coming from the water pump... -
Page 12: Fountain Tier Installation
Fountain Tier Installation For the next step, you will install the fountain tier Step 1: Rest the fountain tier on the side of the into the large bowl. large bowl (Black Arrow). Step 2: Connect the male outlet on the top of the water pump to the tube inside of the fountain tier. Make sure this connection is snug. - Page 13 STOP! At this point, your fountain should look like the image below. Go to the next page for the next step to setup your new Belmont Garden™ Fountain. Remember if you need help contact Customer Care: 1+ (619) 449-2392...
-
Page 14: Step 4: Setting Up Your Fountain
Step 1: Step 4: Setting Up Your Fountain You will need: Water To Fill Your Fountain Fountain Assembled Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 15: Fill Your Fountain
Fill Your Fountain Fill the Fountain Tier until water pours over the spouts. Then fill the Large Bowl until the water is about 1 inch (2.5 centimeters) from the top of the bowl. Operating Your Fountain After you have filled your Fountain, grab both sides of the Large Bowl and quickly shake your Foun- tain for ten seconds. -
Page 16: Troubleshooting And Maintenance
To clean your fountain, drain of all water and disassemble. Use a mild soap and a soft cloth to clean the parts of your Belmont Garden™ fountain. Your fountain bowl will form a natural patina finish which with time may appear lighter or whiter than the original color. This is normal. -
Page 17: Water Pump Impeller
The impeller inside of the Water Pump is what pushes water up through your fountain, allowing you to enjoy the soothing sounds and wonderful sights of your Belmont Garden™ Fountain. After long periods of usage, this part will need to be cleaned to make sure your fountain runs optimally. -
Page 18: Water Pump Connection
Water Pump Connection If your Belmont Garden™ Fountain did not come with the water pump already connected to the tube inside of the fountain tier or if the water pump gets disconnected from the fountain tier, use these instructions to reconnect your water pump. -
Page 19: Using Leveling Shims
Using Leveling Shims If you are having trouble getting water to flow evenly off of the spouts on your Belmont Garden™ Foun- tain, you may need to level the surface that your fountain is placed on. With the included leveling shims, you do not need to move your fountain, just follow the instructions below to get even water flow. - Page 20 LIMITED ONE YEAR WARRANTY This product has a one year limited warranty on all materials and workmanship. Belmont Garden warrants the original purchaser of this product that the product will be free from manufacturing defects in workmanship and material for a period of one (1) year from the date of original purchase. If within...
