About the PC Media Converter (TX/FX)
The McPC (TP-TX/FX) is an IEEE 802.3 single-conversion, 10/100 switch-
ing PC card media converter. It converts 10/100 twisted pair connections
to 100Base-FX 1300 nm multi-mode or 1310 nm single-mode fiber optics.
The fiber port always operates at 100 Mbps FDX; the copper port auto-
senses the connected device's speed and duplex mode: 10 Mbps or 100
Mbps and HDX or FDX (including Flow Control).
The McPC (TP-TX/FX) can be mounted in any PC with a standard PCI or
ISA slot. It includes diagnostic LEDs for each port and a 4-pin peripheral
power supply connector. The McPC (TP-TX/FX) comes with one RJ-45 con-
nector and one pair of ST or SC connectors.
