Industrial Monitor PMG2 series
Capacitive touchscreen
User's manual
Version 1.1
All information contained in this manual, including all photographs, illustrations and software, is protected under international copyright laws, with all
rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written
consent from Panel S.r.l. The information contained herein is believed to be accurate as of the date of publication; however, Panel S.r.l, makes no
warranty, ex- pressed or implied, with regard to the products or documentation contained within this manual. Panel S.r.l. reserves the right to change
the contents of this manual without notice. Panel shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the
use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed. Soft- ware names, hardware names and trademarks are registered by their
respective companies.
www.panel.it
1
1
Advertisement
Table of Contents
Related Manuals for panel PMG2 Series
Summary of Contents for panel PMG2 Series
- Page 1 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from Panel S.r.l. The information contained herein is believed to be accurate as of the date of publication; however, Panel S.r.l, makes no warranty, ex- pressed or implied, with regard to the products or documentation contained within this manual.
-
Page 2: Table Of Contents
2.3 Bespoke front graphic customization ............6 2.4 Touchscreen specifications ................7 2.5 Mechanical dimensions ..................8 2.6 Mechanical cut-out (panel mounting) ............9 2.7 VESA mounting ...................... 10 2.8 Chemicals and solvents resistance ............. 11 Chapter 3: Installation and wiring 3.1 Mounting distance .................... -
Page 3: Chapter 1: Preface
1.1 Safety rules All the monitor PMG2 series have been designed and built taking into account all the issues associated with an industrial environment such as that where it is necessary to ensure the operation of the system in the presence of vibration, moisture, dust and critical heat conditions. -
Page 4: Package Content
Qty 6 Retaining clips (with size 18.5” / 21.5”) 1.4 Declaration of conformity CE Mark, product complies with all applicable directives and their harmonized EN standards. Doc. Int. Panel: 29102014 The products herewith complies to the requirements of: Low voltage directive 2006/95/EC... -
Page 5: Warranty And Rma
2 years, beginning on the date of invoice by Panel. PANEL will engage to repair or eventually replace, at its discretion, the whole device or its components, which show construction defects or malfunction if these are pointed out in writing during the warranty period. -
Page 6: Chapter 2: Technical Data
Chapter 2: Technical data 2.1 Introduction The PMG2 industrial monitors are VESA or panel mounting. The front panel is a tempered IP66 glass supplied with projected capacitive multi-touch screen. 2.2 Products specifications Models PMG212 PMG215 PMG216 PMG217 PMG218 PMG222 Technology construction... -
Page 7: Touchscreen Specifications
Operating Temperature: -25 to 85 ℃ Storage Temperature: -25 to 85 ℃ Relative Humidity: 95% at 60 ℃, RH Non-condensing Interface: USB: 1.1 Full Speed Resolution: 4096×4096 resolution Report rate: USB: Max. 100 points/sec Response time: Max. 25 ms MTBF: 200,000 hrs www.panel.it... -
Page 8: Mechanical Dimensions
All dimensions are specified in mm Display size Model 12.1” projected capacitive touch PMG212 28.5 15.0” projected capacitive touch PMG215 15.6” projected capacitive touch PMG216 28.5 17.0” projected capacitive touch PMG217 88.5 18.5” projected capacitive touch PMG218 28.5 21.5” projected capacitive touch PMG222 150.5 www.panel.it... -
Page 9: Mechanical Cut-Out (Panel Mounting)
2.6 Mechanical cut-out (panel mounting) All dimensions are specified in mm The cut-out tolerance values are +1 mm / -1 mm Display size Model Zmin Zmax Number of retaining clips 12.1” projected capacitive touch PMG212 15.0” projected capacitive touch PMG215 15.6”... -
Page 10: Vesa Mounting
100 corporate members worldwide, and sets industry-wide interface standards for computing environments. Panel agreed on the VESA standard, and all his LCD monitors come with the VESA 100 mounting hole pattern, which means a hole pattern on the back of the monitor: 100mm x 100mm (3.94 x 3.94 inches). -
Page 11: Chemicals And Solvents Resistance
Methylene chloride Projected capacitive touchscreen The touch panel is securely affixed onto the frontal glass. The glass is much more resistant to corrosion than most materials, so much so that it is easy to think of it as corrosion-proof. Optional graphic customization... -
Page 12: Chapter 3: Installation And Wiring
45° When installing the PMG2 in a slanted panel, and the panel face inclines more than 45°, the surrounding air temperature must not exceed 40°C. You may need to use forced air cooling (fan, A/C) to ensure the surrounding air temperature is 40°C or below. -
Page 13: Fasten Pmg2
3.3 Fasten PMG2 Insert the PMG2 into the panel cut. When inserted, fix the Panel PC as shown: (1) Insert each of the fasteners, as shown. (2) Be sure to pull the fastener back until it is flush with the rear of the attachment hole. -
Page 14: Connecting Dc Power
All supplied power must be disconnected before removing device covers or components or installing/removing accessories, hardware or cables. The power cable must be disconnected from the device and from the voltage supply. Verify the correct rated input 110 - 230 VAC, input voltage limits 90…..264 VAC. www.panel.it... -
Page 15: Functional Ground
To avoid excess noise, make the power cord as short as possible. This section describes the precautions for grounding the PMG2 unit: Exclusive grounding (BEST) Exclusive grounding (OK) Common grounding (NOT OK) Important! The motherboard ground and others devices is connected with PMG2 ground. www.panel.it... -
Page 16: Chapter 4: Monitor Connectors
Chapter 4: Monitor connectors 4.1 PMG2 (212÷222) I/O connectors A – Supply connector C – DVI-D B – USB (touch screen reserved) D – VGA 4.2 AD-board layout www.panel.it... -
Page 17: Chapter 5: System Setup
Press the Up / Down keys to move into the menu. Enable the item by pressing the Menu key. Adjust value via the Up / Down keys. MENU Press the Menu key to access the main menu and to activate the sub-menus. www.panel.it... -
Page 18: Chapter 6: Maintenance
Aggressive solvents, chemicals, scouring agents, pressurized air or steam jets should never be used. 6.2 Spare parts It is recommended to install only original Panel spare parts. If the customer mount not original spare parts, we can’t grant the correct work of the device.
