VESA Mount PC PVR-EM series
Intel® N3350 / Intel® N4200
Resistive touchscreen
User's manual
Version 1.1
All information contained in this manual, including all photographs, illustrations and software, is protected under international copyright laws, with all
rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written
consent from Panel S.r.l. The information contained herein is believed to be accurate as of the date of publication; however, Panel S.r.l, makes no
warranty, ex- pressed or implied, with regard to the products or documentation contained within this manual. Panel S.r.l. reserves the right to change
the contents of this manual without notice. Panel shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the
use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed. Soft- ware names, hardware names and trademarks are registered by their
respective companies.
www.panel.it
1
1
Advertisement
Table of Contents
Related Manuals for panel PVR-EM Series
Summary of Contents for panel PVR-EM Series
- Page 1 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from Panel S.r.l. The information contained herein is believed to be accurate as of the date of publication; however, Panel S.r.l, makes no warranty, ex- pressed or implied, with regard to the products or documentation contained within this manual.
-
Page 2: Table Of Contents
4.3 HDD-SSD installation ..................17 4.4 Mini PCI-E and M.2 module installation ............. 18 4.5 WI-FI module installation ................... 19 Chapter 5: Jumpers and connectors 5.1 Motherboard layout…………………………………………………………………………. 20 5.2 PVR I/O connectors ..................... 22 5.3 Motherboard jumpers setup ................23 www.panel.it... - Page 3 Chapter 6: System setup 6.1 Installing operating system ................24 6.2 Bios setup ........................24 6.3 Touchscreen driver and calibration ............24 Chapter 7: Maintenance 7.1 Cleaning........................25 7.2 Lithium battery ......................25 7.3 Spare parts ....................... 25 www.panel.it...
-
Page 4: Safety Rules
PC. Do not disassemble or modify the Panel PC. Doing so may cause a fire or an electric shock. All tasks such as the installation, commissioning and servicing of devices are only permitted to be carried out by qualified personnel. -
Page 5: Package Content
Qty 1 Connector DC supply 1.4 Declaration of conformity CE Mark, product complies with all applicable directives and their harmonized EN standards. Doc. Int. Panel: 29102014 The products herewith complies to the requirements of: Low voltage directive 2006/95/EC EMC Directive 2004/108/EC... -
Page 6: Warranty And Rma
2 years, beginning on the date of invoice by Panel. PANEL will engage to repair or eventually replace, at its discretion, the whole device or its components, which show construction defects or malfunction if these are pointed out in writing during the warranty period. -
Page 7: Chapter 2: Technical Data
Rated input voltage 24 VDC 110 – 230 VAC 9…..36 VDC 90…..264 VAC Input voltage limits Typical Power 28 W Operating Temperature 0° ÷ 50 °C Cooling Type Fanless Conformity 2.3 Bespoke front graphics customization Optional, provided on request www.panel.it... -
Page 8: Touchscreen Specifications
High temperature / Humidity: 70°C / 90% RH, 500 hrs, normal environment for 4 hrs High temperature: 70°C / 500 hrs allow panel stays in normal environment for 4 hrs Low temperature: -40°C / 500 hrs allow panel stays in normal environment for 4 hrs Thermal Cycle: -40°C ~ 70℃... -
Page 9: Mechanical Dimensions
2.5 Mechanical dimensions PVR display units with retaining clips All dimensions are specified in mm Display size Model 15.0” single touch resistive PVR015 11,5 11,5 212,5 www.panel.it... -
Page 10: Vesa Mounting
100 corporate members worldwide, and sets industry-wide interface standards for computing environments. Panel agreed on the VESA standard, and all his LCD monitors come with the VESA 100 mounting hole pattern, which means a hole pattern on the back of the monitor: 100mm x 100mm (3.94 x 3.94 inches). -
Page 11: Chemicals And Solvents Resistance
2.7 Chemical and solvent resistance Aluminum panel overlay The panel overlay withstands 24 hours exposure to the following reagents at 50 °C without visible staining 1.1.1. Trichloroethane Ethylacetate Perchloroethylene Aliphatic hydrocarbons Fluorochlorohydrocarbons Toluene Benzene Glycerine Triacetin Cyclohexanol Glycol Trichloroethylene Diethyl ether... - Page 12 Artificial Perspiration 100.0 (JIS K6772) Optional graphic customization The graphic painted customization is not resistant to the following chemicals: Concentrated mineral acids Concentrated caustic solution High pressure steam at over 100 °C Benzyl alcohol Methylene chloride www.panel.it...
-
Page 13: Chapter 3: Installation And Wiring
For easier maintenance, operation, and improved ventilation, be sure to install the PVR away from adjacent structures and other equipment. See the following drawings. Be sure that the ambient operation temperature and the ambient humidity are within their designated ranges. All dimensions are specified in mm www.panel.it... -
Page 14: Connecting Dc Power
All supplied power must be disconnected before removing device covers or components or installing/removing accessories, hardware or cables. The power cable must be disconnected from the device and from the voltage supply. Verify the correct rated input 110 - 230 VAC, input voltage limits 90…..264 VAC. www.panel.it... -
Page 15: Functional Ground
To avoid excess noise, make the power cord as short as possible. This section describes the precautions for grounding the PVR unit: Exclusive grounding (BEST) Exclusive grounding (OK) Common grounding (NOT OK) Important! The motherboard ground and others devices is connected with PVR ground. www.panel.it... -
Page 16: Chapter 4: Hardware Upgrade
Chapter 4: Hardware upgrade 4.1 Removing the rear cover Warning! Disconnect the power supply to the Panel PC (disconnect the power cable). Isolate the system from all potential sources of electrical power!. Discharge any electrostatic charge on the ground connection... -
Page 17: Hdd-Ssd Installation
Firmly insert the SO-DIMM into the slot until the retaining clips at both ends fully snap back in place and the SO-DIMM is properly seated. 4.3 HDD-SSD installation SATA SSD installation area Unplug the two SATA cables. Then, unscrew the four screws marked above. On the rear of the drive bay there are further four screws that lock the SSD unit. www.panel.it... -
Page 18: Mini Pci-E And M.2 Module Installation
3) Remove the bracket facing the slot that you intend to use. Keep the screws for later use. 4) Align the card connector with the slot and press firmly until the card is completely seated on the slot. 5) Fasten the card to the chassis with screws. 6) Replace the system cover www.panel.it... -
Page 19: Wi-Fi Module Installation
4) Align the card connector with the slot and press firmly until the card is completely seated on the slot. 5) Fasten the card to the chassis with screws. 6) Connect the antenna cable to the main connector of the device: 7) Replace the system cover www.panel.it... -
Page 20: Chapter 5: Jumpers And Connectors
Chapter 5: jumpers and connectors 5.1 Motherboard IMB-156 layout www.panel.it... - Page 21 7 : BL1, BL2 8 : Backlight Volume Control (BLT_VOL1) 9 : Backlight Power Connector (BLT_PWR1) 10 : Panel Power Select (LCD_VCC) (PNL_PWR1) 11 : Digital Input / Output Power Select (JGPIO_PWR1) 12 : 20-pin ATX Power Input Connector 13 : System Panel Header...
-
Page 22: Pvr I/O Connectors
E – PS/2 keyboard port O – Gigabit LAN 1 F – RS232/422/485 (COM 2) P – Gigabit LAN 2 G – VGA Q – Audio Output H – 2x USB 3.0 R – WI-FI Antenna (optional) J – 2x USB 3.0 www.panel.it... -
Page 23: Motherboard Jumpers Setup
Please be noted that the password, date, time, user default profile and MAC address will be cleared only if the CMOS battery is removed. Default PVR015-EM factory setting: 1-2 www.panel.it... -
Page 24: Chapter 6: System Setup
The system is delivered with the optimized defaults preconfigured state and is operational. Changes in the BIOS settings may only be implemented by appropriately trained staff. 6.3 Touchscreen driver and calibration PVR touch screen devices are already calibrated by factory. No calibration is needed. www.panel.it... -
Page 25: Chapter 7: Maintenance
Best Management Practices (BMP). When you discard the Lithium battery in California, USA and the rest of the world, please follow the related regulations in advance. 7.3 Spare parts It is recommended to install only original Panel spare parts. If the customer mount not original spare parts, we can’t grant the correct work of the device. www.panel.it...
