- Page 1 Single-Zone Induction Cooker 單頭電磁爐 Model/型號：EC-1288 Installation & Operating Instructions 產品使用說明書...
-
Page 2: Table Of Contents
CONTENTS 1、 Product Introduction-------------------------------------------------- 3 1.1 .Introduction Of Product 1.2 .Function & Characteristics 2、 Installation Guideline-------------------------------------------------- 4-6 3、 Control Panel Instructions-------------------------------------------- 7 4、 Operation Method----------------------------------------------------- 8-10 4.1 .Operation Instructions 4.2 .Usable and Non-usable Cookware 4.3. Heating Power Level 4.4. Caution 5、... -
Page 3: 1、Product Introduction
1、Product Introduction 1.1、Introduction Of Product： Thank you for choosing Garwoods EC Induction Cooker (Model EC-1288). This product utilizes electromagnetic heating theory and be controlled by the micro-computer touching sensor control system. There are multi-functions which cater for any delicious cuisine. It is the ideal product for modern family. -
Page 4: 2、Installation Guideline
2、Installation Guideline ★ Installation should be followed below requirements： The walls on top of the working face and next to the installation of induction cooker must be heat-proof. The laminated boards and adhesive used for installation must be heat-resistant. For any installation method, the air under the cooker and behind the cooking range should have enough space for cooling in order to ensure the safety of operating the induction cooker. - Page 5 ~ In front of the cabinet, open an air inlet with more than 100cm2 under the location of induction cooker as per illustration II . If the cabinet is not sealed, the air inlet may not be opened so as to ensure heat elimination. illustration II ~ Before put the induction cooker into the hole, an water-proof type is properly applied on the bottom of front panel of the induction cooker as per...
- Page 6 ~ Put induction cooker into hole. Insert plug of power line into corresponding socket. The induction cooker can be used after power connection as per illustration IV . illustration IV ~ If the induction cooker is installed above an oven, fix an insulation part at least 15cm under the induction cooker as per illustration V .
-
Page 7: 3、 Control Panel Instructions
3、Control Panel Instruction Cooking Zone Control Panel 10 9 8 7 6 5 1…On/Off 2…On/Off Indicator 3…Plus Key –Timer 4…touchSlider bar – Power 5…Minus Key – Timer 6…LED Digital Indicator 7…Timer Key 8…Time Indicator 9…Lock Key 10…Lock Indicator... -
Page 8: 4、Operation Method
4、Operation Method 4.1、Operation Instructions： Power Connection After power connection, buzzer will make a short sound and the induction cooker keeps at the stand-by mode. LED digit will show (- - ). Usable and Non-usable Place cookware on heating zone (Pls. refer to On switching Cookware ), by pressing the “ON/OFF”... -
Page 9: Usable And Non-Usable Cookware
4.2、Usable and Non-usable Cookware： ~ Please refer to below information to select a suitable cookware cater for all delicious cuisine by the induction cooker. Usable Cookware Non-usable Cookware Materials Iron, cast iron, stainless steel Materials Cookware made of pottery, and enamel cookware. aluminum, glass, copper or bronze. -
Page 10: Caution
4.4、Caution： Don’t place any metal cooking utensils, e.g. knife, fork, spoon, lid over the heating zone to avoid getting burnt. Don’t place an empty cookware on the heating zone that will cause damage of the induction cooker. Beware of the cookware gets overheated and burnt while heating up oil. Please use level 4 for deep fry cooking. -
Page 11: Warning
5.2、Warning： The induction cooker must not be installed over any metal work top or electrical appliances such as dishwasher, oven, and fridge etc. Do not place metallic objects such as knives, forks, scoops or spoons on the induction cooker, calefaction area in order to prevent any danger caused by high temperature The plate of the induction cooker is hot after cooking;... -
Page 12: 7、Product Specification
7、Product Specification Single-zone Induction Cooker Description Model EC-1288 Power Supply AC220V/50Hz Total Rated Power 2800W Overall Dimension(W x D x H) 345 x 450 x 60 mm Net Weight 7 Kg 8、Trouble-shooting Guideline 8.1、Code Of Breakdown： In case of improper installation or use, abnormal power supply or breakdown of the induction cooker, the LED digit on front panel will display code of breakdown. -
Page 13: Trouble Shooting
8.2、Trouble Shooting： Garwoods’s induction cooker has adopted the most advanced micro-computer inspection and control technology. Some phenomena appeared in the course of working may not indicate problems to occur. Please check the induction cooker according to the follow specifications Situation... - Page 14 目錄 一、 產品簡介---------------------------------------------------------------- 二、 產品安裝說明--------------------------------------------------------- 15-18 控制面板說明----------------------------------------------------------- 19 產品操作說明----------------------------------------------------------- 20-22 五、使用注意事項--------------------------------------------------------- 22-23 六、日常保養注意事項--------------------------------------------------- 23 七、產品規格--------------------------------------------------------------- 八、維修指南--------------------------------------------------------------- 24-25...
-
Page 15: 一、產品簡介
一、產品簡介 Garwoods EC EC-1288) -
Page 16: 二、產品安裝說明
二、產品安裝說明 100mm /mm) ( ) 315 x ( ) 415... - Page 17 100c㎡...
- Page 18 15cm 100c㎡...
-
Page 19: 控制面板說明
三、控制面板說明 10 9 8 7 6 5... -
Page 20: 產品操作說明
四、產品操作說明 (- - ) “4”... - Page 21 12-26cm 4mm) 20kg 120mm 2800W 2400W 2000W 1600W 1200W 800W 400W...
-
Page 22: 五、使用注意事項
五、使用注意事項... -
Page 23: 六、日常保養注意事項
六、日常保養注意事項... -
Page 24: 七、產品規格
七、產品規格 EC-1288 AC220 2800 345x 450x 60 八、維修指南...
