- Page 1 Intelligent Two-zone Infrared Cooker 智能雙頭電陶爐 Model/型號：EC-2220/EC-2228 Installation & Operating Instructions 產品使用說明書...
-
Page 2: Table Of Contents
CONTENTS 1、 Product Introduction-------------------------------------------------- 2 1.1 .Introduction of Product 1.2 .Function & Characteristics 2、 Installation Guideline-------------------------------------------------- 3-5 3、 Control Panel Instructions-------------------------------------------- 6-7 4、 Operation Method----------------------------------------------------- 8-9 4.1 .Operation Instructions 4.2 .Usable and Non-usable Cookware 4.3. Heating Power Distribution 5、 Safety Precautions----------------------------------------------------- 10 5.1 . -
Page 3: 1、Product Introduction
1、Product Introduction 1.1、Introduction Of Product： Thank you for choosing Garwoods EC Infrared Cooker. This product utilizes German EGO radiant heating element. The thermal efficiency is extremely high and reach 500-600 c in just a few seconds. It is controlled by the micro-computer touching sensor control system. -
Page 4: 2、Installation Guideline
2、Installation Guideline ★ Installation should be followed below requirements： The walls on top of the working face and next to the installation of infrared cooker must be heat-proof. The laminated boards and adhesive used for installation must be heat-resistant. For any installation method, the air under the cooker and behind the cooking range should have enough space for cooling in order to ensure the safety of operating the infrared cooker. - Page 5 ~ In front of the cabinet, open an air inlet with more than 100cm under the location of infrared cooker as per illustration II . If the cabinet is not sealed, the air inlet may not be opened so as to ensure heat elimination. illustration II ~ Before put the infrared cooker into the hole, an water-proof type is properly applied on the bottom of front panel of the infrared cooker as per...
- Page 6 ~ Put infrared cooker into hole. Insert plug of power line into corresponding socket. The infrared cooker can be used after power connection as per illustration IV . illustration IV ~ If the infrared cooker is installed above an oven, fix an insulation part at least 15cm under the infrared cooker as per illustration V .
-
Page 7: 3、 Control Panel Instructions
3、Control Panel Instruction Model: EC-2220 Cooking Zone Control Panel 9 8 7 1…On/Off Switch 2…Plus Key 3…LED Digital Indicator (Heating & Timer) 4…Minus Key 5…Timer Key 6…Timer Indicator 7…Lock Key 8…Lock Indicator 9…High Temperature Indicator... - Page 8 Model : EC-2228 Cooking Zone Control Panel 9 8 7 1…On/Off Switch 2…Plus Key 3…LED Digital Indicator (Heating & Timer) 4…Minus Key 5…Timer Key 6…Timer Indicator 7…Lock Key 8…Lock Indicator 9…High Temperature Indicator...
-
Page 9: 4、Operation Method
4、Operation Method 4.1、Operation Instructions： Power Connection After power connection, buzzer will make a short sound. LED Digital Indicator will show ---- and the induction cooker keeps at the stand-by mode. Usable and Non-usable On switching Place cookware on heating zone (Pls. refer to Cookware ), by pressing the “ON/OFF”... -
Page 10: Usable And Non-Usable Cookware
4.2、Usable and Non-usable Cookware： 1. Most of materials for a flat bottom cookware are suitable for use of the infrared cooker, such as stainless steel pot, iron pot, aluminum pot, ceramic pot and glass pot etc. The diameter of the flat bottom cookware is within 12-24 cm. For a good effect, it is recommended for a around 22 cm in diameter and depends on the thickness of the cookware at the flat bottom. -
Page 11: 5、Safety Precautions
5、Safety Precautions 5.1 Safety Notes： The infrared cooker should be immediately plugged out or switch of the socket should be turned off as soon as cooking is finished. No other objects then cookware to be placed on the calefaction area. Do not insert any objects like iron wire etc. -
Page 12: 6、Daily Maintenance
7、Product Specification Description Intelligent Two-zone Infrared cooker Model EC-2220/EC-2228 Power Supply AC220-240V/50Hz Total Rated Power 2800W 750 x 450 x 65 mm (EC-2220) Overall Dimension(W x D x H) 710 x 410 x 65 mm (EC-2228) 10 Kg Net Weight... -
Page 13: 8、Trouble-Shooting Guideline
High power voltage Low Power voltage 8.2、Trouble Shooting： Garwoods’s infrared cooker has adopted the most advanced micro-computer inspection and control technology. Some phenomena appeared in the course of working may not indicate problems to occur. Please check the infrared cooker according to the follow specifications... - Page 14 目錄 一、 產品簡介---------------------------------------------------------------- 二、 產品安裝說明--------------------------------------------------------- 15-17 控制面板說明----------------------------------------------------------- 18-19 產品操作說明----------------------------------------------------------- 20-21 五、使用注意事項--------------------------------------------------------- 22 六、日常保養注意事項--------------------------------------------------- 23 七、產品規格--------------------------------------------------------------- 八、維修指南---------------------------------------------------------------...
-
Page 15: 一、產品簡介
一、產品簡介... -
Page 16: 二、產品安裝說明
二、產品安裝說明 100mm /mm) ( ) 670 x ( ) 350 x ( ) 100... - Page 17 100c㎡...
- Page 18 15cm 100c㎡...
-
Page 19: 控制面板說明
三、控制面板說明 型號: EC-2220 9 8 7... - Page 20 型號: EC-2228 9 8 7...
-
Page 21: 產品操作說明
四、產品操作說明 1400... - Page 22 °...
-
Page 23: 五、使用注意事項
五、使用注意事項 刻讓 朋友 禁 毒碗 雪 焗 洗碗碟 金 刀 叉 勺 溫影響 留 溫頗 ° 泠 況 破 商 授權 維修 業人 員 換維修 得 換拆卸 否則 予 修 公司概 負責 破裂 商 授權 維修 業人員 換維修... -
Page 24: 六、日常保養注意事項
沖洗 髒污 候 布沾 擦拭 擦 稀 去污粉 布擦拭 溶 含苯 化學崇藥 擦拭 化學 硬刷子刷洗 摩擦 刮 刮 影響 期 污漬 灰塵 七、產品規格 EC-2220/EC-2228 AC220-240伏 /50赫玆 2800 750 x 450 x 65毫 (EC-2220) 710 x 410 x 65毫 (EC-2228) 10千克... -
Page 25: 八、維修指南
八、維修指南 供 供 供 了 檢測 象 味 檢...
