- Page 1 Two-Zone Induction Cooker 雙頭電磁爐 Model/型號：EC-2368IC Installation & Operating Instructions 產品使用說明書...
-
Page 2: Table Of Contents
CONTENTS 1、 Product Introduction-------------------------------------------------- 3 1.1 .Introduction Of Product 1.2 .Function & Characteristics 2、 Installation Guideline-------------------------------------------------- 4-6 3、 Control Panel Instructions-------------------------------------------- 7 4、 Operation Method----------------------------------------------------- 8-10 4.1 .Operation Instructions 4.2 .Usable and Non-usable Cookware 4.3. Heating Power Distribution 4.4. Examples Of Cooking Application 4.5. -
Page 3: 1、Product Introduction
1、Product Introduction 1.1、Introduction Of Product： Thank you for choosing Garwoods EC Induction Cooker (Model EC-2368IC). This product utilizes electromagnetic heating theory and be controlled by the micro-computer touching sensor control system. There are multi-functions which cater for any delicious cuisine. It is the ideal product for modern family. -
Page 4: 2、Installation Guideline
2、Installation Guideline ★ Installation should be followed below requirements： The walls on top of the working face and next to the installation of induction cooker must be heat-proof. The laminated boards and adhesive used for installation must be heat-resistant. For any installation method, the air under the cooker and behind the cooking range should have enough space for cooling in order to ensure the safety of operating the induction cooker. - Page 5 ~ In front of the cabinet, open an air inlet with more than 100cm2 under the location of induction cooker as per illustration II . If the cabinet is not sealed, the air inlet may not be opened so as to ensure heat elimination. illustration II ~ Before put the induction cooker into the hole, an water-proof type is properly applied on the bottom of front panel of the induction cooker as per...
- Page 6 ~ Put induction cooker into hole. Insert plug of power line into corresponding socket. The induction cooker can be used after power connection as per illustration IV . illustration IV ~ If the induction cooker is installed above an oven, fix an insulation part at least 15cm under the induction cooker as per illustration V .
-
Page 7: 3、 Control Panel Instructions
3、Control Panel Instruction Cooking Zone Control Panel 9 10 11 1…LED Digital Indicator (Timer) 2…Time Indicator 3…Timer Key 4…Minus Key (Timer) 5…Plus Key (Timer) 6…LED Digital Indicator (Heating)- Front 7…Minus Key (Heating) - Front 8…Plus Key (Heating) - Front 9…On/Off Switch - Front 10…LED Digital Indicator (Heating)- Back 11…Minus Key (Heating) - Back 12…Plus Key (Heating) - Back... -
Page 8: 4、Operation Method
4、Operation Method 4.1、Operation Instructions： Power Connection After power connection, buzzer will make a short sound and the induction cooker keeps at the stand-by mode. Usable and Non-usable Place cookware on heating zone (Pls. refer to On switching Cookware ), by pressing the “ON/OFF” key, LED digit will show the pre-set power level 6(Back) or 5(Front). -
Page 9: Usable And Non-Usable Cookware
4.2、Usable and Non-usable Cookware： ~ Please refer to below information to select a suitable cookware cater for all delicious cuisine by the induction cooker. Usable Cookware Non-usable Cookware Materials Iron, cast iron, stainless steel Materials Cookware made of pottery, and enamel cookware. aluminum, glass, copper or bronze. -
Page 10: Examples Of Cooking Application
4.4、Examples Of Cooking Application： Below information is given for reference only. Level Suitable for Re-heat, melting sauce, Boiling soup and porridge(e.g. Fry omelettes, baked eggs), heating up ready-cooked meals…. Steaming vegetables, fish or braising meat…. Cooking larger portion of food, stews and soups…. Light stir frying escalopes, veal, cutlet, rissoles, sausages, eggs, pancakes…. -
Page 11: 5、Safety Precautions
5、Safety Precautions 5.1 Safety Notes： The heating of the induction cooker is based on the principium of the magnetic induction so that some induction electric current could be caused around the cooker. Although the test shows that induction cookers do not harm the standard pacemaker users, but you are still advised to consult your doctor before using the induction cooker. -
Page 12: 6、Daily Maintenance
The air inlet should be cleaned regularly in order to have a good ventilation condition. 7、Product Specification Description Two-zone Induction Cooker Model EC-2368IC Power Supply AC220V/50Hz Total Rated Power 2800W Overall Dimension(W x D x H) 288 x 510 x 65 mm... -
Page 13: 8、Trouble-Shooting Guideline
High power voltage Low Power voltage 8.2、Trouble Shooting： Garwoods’s induction cooker has adopted the most advanced micro-computer inspection and control technology. Some phenomena appeared in the course of working may not indicate problems to occur. Please check the induction cooker according to the follow specifications... - Page 14 目錄 一、 產品簡介---------------------------------------------------------------- 二、 產品安裝說明--------------------------------------------------------- 16-18 控制面板說明----------------------------------------------------------- 19 產品操作說明----------------------------------------------------------- 20-22 五、使用注意事項--------------------------------------------------------- 23 六、日常保養注意事項--------------------------------------------------- 24 七、產品規格--------------------------------------------------------------- 八、維修指南---------------------------------------------------------------...
-
Page 15: 一、產品簡介
一、產品簡介 Garwoods EC EC-2368IC) -
Page 16: 二、產品安裝說明
二、產品安裝說明 100mm /mm) ( ) 280 x ( ) 490 x ( ) 100... - Page 17 100c㎡...
- Page 18 15cm 100c㎡...
-
Page 19: 控制面板說明
三、控制面板說明 9 10 11 1… 2… 3… 4… 5… 6… 7… 8… 9… 10… 11… 12… 13… 14… 15…... -
Page 20: 產品操作說明
四、產品操作說明 6( ) 5( ) - Page 21 12-26cm 4mm) 20kg 120mm 2800W 2800W 200W 200W 400W 400W 600W 600W 1000W 1000W 1400W 1400W 1800W 2200W...
-
Page 23: 五、使用注意事項
五、使用注意事項... -
Page 24: 六、日常保養注意事項
六、日常保養注意事項 七、產品規格 EC-2368IC AC220 2800 288x 510x 65... -
Page 25: 八、維修指南
八、維修指南...
