Mo Systeme modulbox Manual page 21

The supply takes place via a 230V / 16A safety plug which is pulled out
on the back (side C) of the modulbox below the building frame.
A green sticker attached to the base frame indicates the position of the
plug behind it.
The system must be checked for mechanical damage before each start-
up or each time the modulbox is rebuilt. In particular, the connection
lines must be checked for mechanical damage and contamination of the
contacts on the connectors.
The FI circuit breaker and the fuses for the light and socket outlet
circuit are located under one of the perforated plates in the connection
box provided for this purpose.
The light ceiling is designed with fluorescent tubes in some module
boxes, in others with LED systems
The light ceiling is switched on and off by briefly pressing the button
on the control unit. With some versions, the brightness of the luminous
ceiling can be regulated (dimming) by pressing the button longer.
Dismantling cover light ceiling
To dismantle the light ceiling, first remove the perforated sheets held
by magnets. Then the screw connections on the side can be loosened
and the frame with the light ceiling film removed.
Warning notice:
Work on the electrical system may only be carried out by qualified
personnel!
Protect luminous ceiling film from mechanical influences of any kind
E Roof terrace optional equipment
For a roof terrace with 4m² (modulbox standard) a maximum
number of visitors of 5 people applies, for a modulbox MAX roof
terrace with 8m², a maximum number of visitors of 10 people.
The user must ensure compliance with the limitation.
The railings of the terrace are designed in such a way that they
take over parts of the static loads.
The roof terrace of the modulbox is accessed via a staircase
that is attached to the intended position or is already attached
during transport.
Automatic stairs and terrace railings
This stair system is divided into two parts and partially folded
onto the base frame of the modulbox during transport. After
unlocking the transport lock, the stairs fold out into their end
position with the aid of gas springs. The lower part is delivered
