- Page 1 Digital radio-controlled weather station Operating instructions Warranty Base station: GT-WS-10s GT-WS-10w GT-WS-11s GT-WS-11w Radio sensor: GT-WT-02 YEARS WARRANTY 11/2014...
-
Page 2: Table Of Contents
Contents Safety ..............5 Contents of delivery . - Page 3 Contents Time functions ............33 Time and date .
- Page 4 Contents Reset weather station ............51 Have time displayed in a different time zone .
-
Page 5: Safety
Safety Please read carefully through the following information and keep these instructions, in case you need to refer to them later. If you pass the product on to someone else, please also include these instructions. This device may be used by children from the age of 8 as well as by persons with reduced physical, sensory and mental capabilities or with a lack of experience and/or knowledge if they are being supervised or have been instructed on how to... - Page 6 The radio weather station and the mains adaptor must not be immersed in water or other iquids due to risk of electrocution. The base station of the radio weather station must not be used near sources of moisture such as sinks. Only the mains adaptor provided must be used and it must only be replaced with the same model.
- Page 7 Hazards for children Batteries can pose a danger to life if swallowed. Therefore, keep the weather station, radio sensor and batteries out of reach of small children. If a battery has been swallowed, medical assistance must immediately be sought. Keep children away from packaging material and the small parts in the scope of delivery.
- Page 8 Pull the mains adaptor out of the socket: - before cleaning the radio weather station, - if the device is obviously not working properly, - during thunderstorms Always pull the plug, not the cable. Do not modify the device itself or the power cable. Repairs must only be carried out by a specialist workshop, because devices that have not been professionally repaired may put the user at risk.
- Page 9 Caution – property damage Protect the base station and radio sensor from dust, impact, extreme temperatures and direct sunshine. Protect the base station from moisture. Exclusively position base station in a dry, enclosed space. The radio sensor is protected against moisture; however, it must be protected from direct exposure to moisture such as rain.
-
Page 10: Contents Of Delivery
Always replace all batteries in the base station or in the radio sensor at the same time. Only use batteries of the same type, do not use different types or used and new batteries together. Do not carry out any changes to the device. Only allow repairs to be carried out by a professional workshop and pay attention to the warranty conditions. -
Page 11: Weather Station Functions
Weather Station Functions Base station High-resolution colour display Precise time through reception of a time indicator signal 12-hour or 24-hour display for two time zones Date and day of week display Inside temperature display in °C/°F Outside temperature display in °C/°F with up to three sensors at various measuring points Inside and outside humidity display Minimum/maximum display for temperature, atmospheric humidity and... - Page 12 Sensor Temperature display in °C/°F Humidity display Range of up to 100 metres (in open space)
-
Page 13: Overview Of Weather Station
Overview of weather station Base station - front Display see page 30... - Page 14 Base station - back...
- Page 15 Control elements and parts of the base station (back) Light up display, switch off light Activate snooze function Mounting eyelet Control buttons (see next page) Fold-away support (two positions) Battery compartment Plug-in point for mains adaptor (the plug-in point on some models is on the opposite side)
- Page 16 Base station - Control buttons (back) MIN/MAX Display saved MIN and MAX data Set values (decrease) -/ /ZONE Manually start radio reception Set values (increase) Switch alarm function on and off MODE/ Activate setup mode Save your settings BARO+ Set air pressure of location (increase) SET/BARO Activate setup mode for air pressure BARO- Set air pressure of location (decrease)
- Page 17 Radio sensor Battery compartment Change degree of measurement for temperature Accelerate radio transmission Set sensor number to base station manually (transmission channel)
-
Page 18: Initial Use
Initial use Proceed in the order indicated and first insert the batteries in the radio sensor. Only then will the weather station work properly. Radio sensor Remove the battery compartment lid on the back of the radio sensor. Insert two type R03 (AAA) / 1.5 V batteries, as shown on the base of the battery compartment. - Page 19 - Do not use any rechargeable batteries, as their voltage is too low (only 1.2 V instead of 1.5 V). This influences the measuring precision, among other things. - Preferably use alkaline batteries instead of zinc carbon batteries. Alkaline batteries last longer, particularly with low outdoor temperatures. Using additional radio sensors The weather station is supplied with one radio sensor.
-
Page 20: Base Station
Reattach the battery compartment lids onto the radio sensors. Keep the CHANNEL button pressed on the base station until the display for weather data OUT flashes. The base station will now access the weather data for all available radio sensors. Base station You can operate the radio weather station with a mains adaptor or with batteries. -
Page 21: Setting Air Pressure
Wait approx. 30 minutes. During this time the base station gathers all weather data and receives radio signals from the time signal transmitter. Battery operation Fold open the battery compartment lid. Insert two type LR6 / 1.5 V batteries, as shown on the base of the battery compartment. -
Page 22: About The Time Signal
Keep the SET/BARO button pressed until the display that shows the air pressure begins to flash. Using the BARO- / BARO+ buttons, set the air pressure. Pay attention to what is shown in the display. Then, press SET/BARO again. If you keep the BARO- / BARO+ pressed, the values move forward more quickly. -
Page 23: Start Radio Reception Automatically
The base station switches on several times a day and synchronises its time with the radio signal from transmitter MSF. In the case of non-receipt, e.g. with strong lightning storms, the device continues to run accurately and only switches to receiving automatically at the next designated time. -
Page 24: Set Time And Date Manually
In this case, the time continues to run normally, from the start time of "00:00". First, check whether the location of the base station is suitable, see page 27. You can restart the receiving process again manually, see page 23, or Wait until the base station automatically switches to receiving again later. - Page 25 Press the MODE/SET. button to save the setting. The hour flashes in the display. Using the +/ or -/ /ZONE buttons, set the correct hour. Press the MODE/SET. button to save the setting. The minute flashes in the display. Using the +/ or -/ /ZONE buttons, set the correct minute.
-
Page 26: Start Radio Reception Manually
Press the MODE/SET. button to end the process. Start radio reception manually If the adjacent radio signal symbol is no longer displayed, the radio signals of the time signal transmitter are no longer being received. The time display nevertheless continues to run accurately. In order to start the reception of the time signal manually, keep the -/ /ZONE button pressed until the radio signal symbol is displayed again and the weather station is switched to reception. -
Page 27: Select Location
Select location ATTENTION - Protect the base station and radio sensor from dust, impact, extreme temperatures and direct sunshine. - Protect the base station from moisture. Exclusively position base station in a dry, enclosed space. - -The radio sensor is protected against moisture; however, it must be protected from direct exposure to moisture such as rain. - Page 28 Devices, such as televisions, cordless telephones, computers and neon tubes can also disrupt the radio reception. Do not place the base station and radio sensor directly on the ground. This limits the range. At low temperatures during the winter, the performance of the radio sensor batteries can fall significantly.
- Page 29 The weather, e.g. an intense lighting storm, can cause reception problems. The transmitter can occasionally be switched off temporarily, e.g. for maintenance works. Base station DANGER When installing on a wall, please ensure that no electric cables, gas and water pipes are not buried beneath the wall surface before drilling any holes.
-
Page 30: Displays
Displays Base station... - Page 31 Weather data, see page 36 Date and weekday display, see page Moon phase display, see page Time and alarm time display, see page Air pressure display, see page Weather forecast, see page...
-
Page 32: Radio Sensor
Radio sensor Symbol for radio link between base station Temperature and radio sensor (displayed only during radio transmission) Humidity set sensor number (= transmission channel) -
Page 33: Time Functions
Time functions Time and date Symbol for alarm 12-hour format Symbol for radio Time zones reception from time signal transmitter Time in hours, minutes + seconds Current day of week Day and month... -
Page 34: Alarm Function
Alarm function You can set two different alarm times with the base station. Select the required alarm time by pressing the MODE/SET. button (A1 or A2). Keep the MODE/SET. pressed for approx. 2 seconds, when you have selected the required alarm time. The hour display of the alarm time (A1 or A2) flashes. - Page 35 Press 2x: A2 is active is displayed Press 3x: A1 and A2 are active is displayed Press 4x: A1 and A2 are no longer active is extinguished End alarm At the set time, you will be woken up by an alarm signal, whereby the signal will increase in intensity, the longer the alarm sounds.
-
Page 36: Weather Data
The alarm becomes silent for approx. 5 minutes. After this, the devices switches itself back on and wakes you up again. This process can be repeated several times. In this context please also note the section starting on page 46. Weather data Temperature and humidity This area is divided into two parts in the display. - Page 37 Display area Radio sensor Current transmission channel to the base station Stored maximum and minimum values Trend for temperature, see page 36 Battery replacement display, see page 50 Trend for humidity, see page 36 Humidity in % Degree of measurement for temperature °C or °F Temperature Indication that the sensors are automatically queried sequentially (only if more than one sensor is being used)
- Page 38 With the CHANNEL button, you can switch between the radio sensors: CH1, CH2, CH3 or automatic switching between all sensors. If fewer than three sensors are in use, non-existent radio sensor are skipped with the switching. If only one radio sensor is in use (standard), the auto-switching function is not available.
- Page 39 Humidity in % Degree of measurement for temperature °C or °F Temperature With the MIN/MAX button, you can obtain a display of the highest and lowest values for the last 24 hours in relation to the temperature and humidity. Press 1x: the MAX values are displayed Press 2x: the MIN values are displayed Press 3x: normal display The MIN and MAX values are automatically deleted each night at 12:00 a.m.
-
Page 40: Weather Trend
Weather trend For the temperature and humidity values measured by the base station and radio sensor, the trend is shown in the form of an arrow. trend rising constant falling Temperature Humidity Air pressure The trend of the air pressure within the last 12 hours is displayed in the form of a bar diagram. -
Page 41: Weather Forecast
The MAX and MIN values are continuously measured and stored. It is therefore not possible to manually delete these values. In conjunction with the weather forecast, see next chapter, other weather indications are possible. Two examples: Weather forecast shows rain, the air pressure is falling quickly and intensively >> strong rain is likely. - Page 42 The precision of the weather forecast is approximate only. sunny slightly cloudy cloudy rainy...
- Page 43 thunderstorm light snowfall Frost warning - When the radio sensor measures a temperature of between + 1 °C and -1 °C, a risk of frost exists and a snowflake symbol flashes. If the temperature falls below -1 °C for a constant period of time, the snowflake symbol is displayed heavy snowfall steadily.
- Page 44 If a radio sensor is in use, the frost alarm will be identified from the sensor unit with the lowest number. If the symbols for the weather forecast start to flash and the air pressure falls, this is an indication of weather deterioration, e.g. because of a storm front closing in. However, the requirement for a correct display is that you have set the air pressure at your location, see page 21.
-
Page 45: Moon Phases
Moon phases The displayed moon phases are automatically updated with the date full moon waning moon new moon new moon waxing moon full moon... -
Page 46: Switching The Light On
Switching the light on Battery operation Press the LIGHT/SNOOZE button in order to switch on the display lighting for several seconds. Mains supply operation If the base station is operated through the power supply using the mains adaptor, the display is always lit. Press the LIGHT/SNOOZE button to switch the display light on or off. - Page 47 Example 1: button Alarm tone off - mains supply operation Alarm - display light is ON Light on sounds - it’s wake-up time Display light is on SNOOZE/LIGHT After approx. button 5 minutes Alarm tone off Alarm tone on Light on Light on SNOOZE active button...
- Page 48 Example 2: button Alarm tone off - mains supply operation Alarm - display light is OFF Light off sounds - it’s wake-up time Display light is on SNOOZE/LIGHT After approx. button 5 minutes Alarm tone off Alarm tone on Light off Light on SNOOZE active button...
- Page 49 Example 3: button Alarm tone off - battery operation Alarm - display light is OFF sounds Light off - it’s wake-up time Display SNOOZE active light is on SNOOZE/LIGHT After approx. button 5 minutes Alarm tone off Alarm tone on Light off Light on SNOOZE/LIGHT...
-
Page 50: Other Functions
Other Functions Battery replacement display There is a battery change display for each of the base station and radio sensor. When the symbol for the battery change is displayed, the inserted batteries in the base station (symbol next to IN)/radio sensor (symbol next to OUT) need to be replaced with new ones. -
Page 51: Change Degree Of Measurement For Temperature
Change degree of measurement for temperature The temperature can only be displayed in either °C or in °F on the base sensor and radio sensor. Base unit Keep the MIN/MAX button pressed for approx. 2 seconds, in order to change the displayed unit of measurement. -
Page 52: Have Time Displayed In A Different Time Zone
After approx. 20 seconds, the display begins to flash and the data from the radio sensors is queried. Pay attention to the displayed values. If incorrect values continue to be displayed: Remove the batteries from the radio sensors used and reinsert them. Proceed as described from page 18 . - Page 53 Each country is allocated to a time zone, whereby countries with a very large east-west expansion frequently extend over several time zones. Russia, for example, extends across 9 time zones, Canada extends over 5 time zones.
-
Page 54: Faults And Rectification
In the western hemisphere, it is earlier than in Europe and in the eastern hemisphere, it is later. In the graphic each vertical line corresponds to one hour more (+) or one hour less (-). For example, if you want to set the time for a specific country that is 7 hours east of your location, you have to enter the value +7 (hours). - Page 55 The weather station does not - Ensure that no electrical disruption sources receive any sensor signals. are near the sensor or the base station. - Check the batteries in the sensor. - Start the radio reception manually: Keep the CHANNEL button pressed on the base station until the display for weather data OUT flashes.
-
Page 56: Technical Data
Technical data Base station GT-WS-10s / GT-WS-10w / GT-WS-11s / GT-WS-11w Model: Input: 3,0-3,6 V , max. 100 mA Batteries: 2 x LR6 (AA) / 1.5 V / max. 41 mA Protection class: Measurement range of the temperature 0 °C to +50 °C Measurement precision: max. - Page 57 Splash protection: IP31 Transmission frequency 433 MHz Range: max. 100 metres (in open space) Mains adapter Model: KB1B-036-0100D Input: 230 V~, 50Hz Output: 3,6 V , 100 mA Splash protection: IP20 Protection class: As our products are constantly being further developed and improved, design and technical changes are possible.
-
Page 58: Cleaning
Cleaning In the case of mains supply operation: remove the mains adaptor plug from the base station. If required, wipe the weather station with a slightly dampened cloth. Dry the device completely before connecting it to the mains adaptor again. Conformity declaration Globaltronics GmbH &... -
Page 59: Disposal
Disposal Dispose of the packaging in an environmentally appropriate manner. The appliance must not be disposed of with household waste. If the appliance should no longer usable, remove the batteries from the appliance. Ask the local waste removal association about the necessary disposal measures. Batteries and rechargeable batteries are not permitted to be disposed of with household waste. -
Page 61: Warranty Card
Warranty card YEARS WARRANTY Productname: Radio-controlled weather station Please send your completed Warranty Card to: Base station: GT-WS-10s GT-WS-10w GT-WS-11s Globaltronics Service Centre GT-WS-11w c/o Bridges London Radio sensor: GT-WT-02 PO BOX 1125 Bromley Date-Code: 11/2014 BR1 9TW Product no.: 91647 Customer name: Hotline - UK: 0800 / 328 6020... - Page 62 Warranty card Model: Base station: GT-WS-10s, GT-WS-10w, GT-WS-11s, GT-WS-11w, Radio sensor: GT-WT-02 The appliance has been manufactured with the greatest care. The warranty period is three years from the date of purchase. Please retain the sales receipt as proof of purchase as without it the warranty claim cannot be processed.
