I-Tech HRKP115 Specifications

HRKP115
HRKP115
HRKP115-801
HRKP115-801
HRKP115-1601
HRKP115-1601
w/ KVM function
Specification
Monitor
Panel 15" LCD panel
Display type TFT/ LCD active matrix color
Resolutions 1024 x 768
Response time Tr=5ms/ Tf=20ms
Screen dimming ratio 200 : 1
Contrast ratio 300 : 1 typical
Brightness 1400 cd/ m
Pixel pitch 0.297mm (H) x 0.297mm (W)
Panel color 16.7 million display colors
Viewing angle 115˚ (Horiz.)/ 100˚ (Vert.)
Storage temp. -20˚C to 60˚C
Operating temp. 0˚C to 50˚C
MTBF 25,000 hours
Backlight
• Number of lamps 12
• Power consumption 35W
Power supply
• Remote adapter: 110V - 220V AC Input
12V 5A Output
• Adapter Size: 10.8(L) x 6.1(W) x 3(H)cm
• Cable length from mains plug to adapter: 182cm
• Cable length from adapter to unit: 180cm
• Safety approval: UL, CE
• Mains plug options available
Product dimension-
Packing dimension-

Ordering Information

Model no.
HRKP115 K
HRKP115-801 K
HRKP115-1601 K
K Keyboard Selection code : e = Notebook type K/B w/ touch pad mouse; c = Cherry K/B w/ trackball
US Toll Free: 1-888-483-2418 or 1-510-589-4137 Fax: 1-510-372-2736
1.5U
monitor keyboard drawer / KVM switch
2
typical
43.9(W) x 6.6(H) x 60(D)cm
73.5(L) x 57.5(W) x 18(H)cm
Description
1.5U height, 15" high bright TFT LCD monitor
keyboard drawer
1.5U height, 15" high bright TFT LCD monitor
keyboard drawer with 8 port KVM switch
1.5U height, 15" high bright TFT LCD monitor
keyboard drawer with 16 port KVM switch
i-Tech Company, P.O. Box 4134, Hayward, CA 94540
Rackmount high bright 15" TFT LCD
Dimension
1.5U
Net / gross weight
11kg / 19kg
12kg / 21kg
13kg / 22kg
Unit : mm
22
