I-Tech ELD117e Specifications

ELD-117e : 1U Rackmount 17" LCD Drawer Touch - Pad Keyboard with Speakers
Model: ELD117e
Display Performance
Items
Screen Diagonal
Active Area
Pixel H x V
Pixel Pitch
Pixel Arrangement
Display Mode
White Luminance
Contrast Ratio
Optical Response Time
Nominal Input Voltage
Power Consumption
Support Color
Temperature Range
Operating
Storage (Shipping)
Mechanical Drawings
www.i-techcompany.com,
Specifications
17 inches
337.92 (H) x 270.336(V)
1280 x 1024
0.264(H) x 0,264(W)
R.G.B Vertical Stripe
Normally White
2
250 cd/m
350:1 (Typ)
Tr = 5ms / Tf = 20ms
+5.0 V
45W
16.7 M colors (RGB 8-bit data)
0
0 to +50 C
0
-20 to +65 C
Toll Free: 1-888-itech-18 (1-888-483-2418), Fax: 1-510-372-2736.
Features:
•
1U 17" rack mount LCD keyboard drawer
•
Built- in speakers and audio- in jack
•
Notebook keyboard (IBM PC / AT compatible)
•
PS/2 touch-pad
•
Max depth with adjustable bracket: 30.12 inches
•
88- key separated numerical key pad
•
Integrated 2-button touch pad pointing device
•
Removable power supply.
•
Operating temperature 0 to 60 degree C
•
Humidity 20% to 85%RH
•
19"(W) x 17.5"(D) x 1.75"(H)
•
Detached Power supply unit
•
Black color

Power supply

Built-in adapter: 110V - 220V AC Input 12V 5A Output
Cable length from mains plug to adapter:
Safety approval:
Product dimension
19" (W) x 1.75" (H) x 19.4" (D)
Packing dimension
24" (L) x 24" (W) x 7" (H)
Weight
Model No KVM
ELD117e Non
6ft (182cm)
UL, CE
Net / Gross weight
Approx 35 lbs
