- Page 1 ZEN FLOAT TANK ASSEMBLY INSTRUCTIONS VIDEO INSTRUCTIONS: https://www.youtube.com/zenfloatco Check online for version updates at: zenfloatco.com. Version 1.0, updated 10/03/2018. For help with watercare maintenance go to: zenfloatco.com/water-care/...
- Page 2 CONTENTS Air Pump Tank Base Tank Body Floor Heater Vent Cap Temperature Controller Pump & UV Filter Grounding Probe GFCI Adapter...
- Page 3 Filter Bag T Fitting 90 Deg. Fitting Hose Hose Clamps Pump Manifold Hydrometer Inline Carbon Filter Water Test Strips...
- Page 4 1. CHOOSE PROPER PLACEMENT Choose a prefered location that will be at least 68 degrees Fahrenheit. Allow at least 1 ft (30 cm) of space between the Float Tank and room walls for maintenance. NOTE: It is recommended to place your tank in a room that maintains approx.
- Page 5 3. PLACE HEATER PADS The heater pads are designed to be placed on top of the tank base that was set up during step one, and will radiate the heat up toward the tank that sits directly on the heater pads.
- Page 6 IMPORTANT VERIFY THE PADS ARE THE CORRECT SIDE UP! They will have markings on each pad to verify which side is up. Lay down radiant pads so they are just barely touching each other.
- Page 7 BURNS Use heating pads only as directed. Confirm that the heating element in the heating pad is facing upward. While the heating pad is activated, do not leave in contact with any object other than the waterproof liner as directed, and avoid direct contact of skin with the heating pad.
- Page 8 NOTE: Each valve has a pin in the center that can be manually pushed down to deflate the wall. If you push down and turn the pin the airway will stay open for easy deflation. When inflating a panel, check that the pin is in the proper position to hold air.
- Page 9 Start by setting pump (B) in place and then attach the premade joint piece (A) on top of it. This would be the time to make sure it aligns...
- Page 10 well with your filter bag (C) in place. Adjustment may be necessary. Route the plug wires through the neoprene sock to the outside of the tank. Connect the rest of the filtration line using the hose clamps. The hoses should connect together with some force. Be sure to use the T connector in the middle, followed by the elbow at the end.
-
Page 11: Risk Of Electrical Shock
NOTE: Plug in the pads temporarily to verify they weren’t damaged in transit. The pads will heat almost too hot to touch. Plug everything with the tank through the GFCI provided or one of your choosing. GFCI’s cut the power if the electricity ever comes in contact with the water. - Page 12 (13 cm) of water. Add 100 lbs (45 kg) of salt at a time, mixing in fully as you go. NOTE: If you bought your salt from Zen Float Co., we provide 850 lbs (385 kg) of salt per pallet, you won’t use it all to fill your tank. Only 800 lbs (363 kg).
-
Page 13: Property Damage
ADDITIVES AND SALT INGESTION Do not add additives (such as bubble bath and bath salts) to the water in the Float Tank, other than Epsom salt as directed. Do not ingest the water in the Float Tank. PROPERTY DAMAGE Do not overfill the Float Tank. Never leave the Float Tank unattended when filling with water. - Page 14 8. TURN ON AND VERIFY SETTINGS Plug the two heating pads into the Temperature Controller. Plug the UV Filter in. The first thing you will notice is a slight glow from the UV filter. The temperature will now display a temperature detected by the attached temperature sensor.
- Page 15 You should now see the heating indicator light turn on and within minutes be able to feel warmth coming up through the pads in your tank. 9. INSTALL AIR VENTS Insert vent stem through vent holes on the back of the Float Tank and snap together with the other half of the vent on the other side.Tuck in three tabs to start and use finger to tuck the fourth in.
-
Page 16: Fire Hazard
ASPHYXIATION Lack of ventilation may cause injury or death. Before entering the Float Tank, confirm that the air vent stems are inserted as directed and functioning properly. IMPORTANT ALWAYS CHECK YOUR TEMPERATURE BEFORE GETTING INTO THE FLOAT TANK. DO NOT EVER FLOAT IF THE TEMPERATURE IS ABOVE 96º... - Page 17 DRUGS AND ALCOHOL USE Do not use drugs or alcohol before or during use of the Float Tank. The use of drugs or alcohol may increase the risk of injury, unconsciousness, and possible drowning. SLIPPING AND FALLING To avoid falling or other injury, use caution when entering or exiting the Float Tank.
- Page 18 Zen Float Co. 6810 S 300 W #5 Midvale, UT 84047 Tel: (855) Zen-Float Email: info@ZenFloatCo.com...
