I-Tech DuroView DVX104 Specifications

Industrial Monitor
Duro-View (DVX)
Series
Rugged industrial TFT LCD panel mount with NEMA 4
Optional for Touch screen
Features
＊ Front panel NEMA4 / IP65 meet.
＊ High resolution, high brightness and contrast.
＊ Long-life backlight.
＊ Anti-Reflective window.
Option
＊ Video input (S-Video, Composite).
＊ OSD key position choice.
＊ Aluminium front bezel.
＊ Optional White or Black Bezel
Ordering information
DVX
xxx xxx - xx x
Ⓐ ⒷⒸⒹ
Ⓐ : Display size
104: 10.4"
170: 17.0"
Ⓑ : Front cover code
M: Powder coated steel
Ⓒ : OSD board position
F: Front
Ⓓ : Input signals
T : Audio, RGB
A : RGB, DVI, Composite, S-Video, Audio(15.0"/17.0"/19.0")
J : RGB, Composite, S-Video, Audio(10.4"/12.1")
Ⓔ : Touch Screen type
NIB: Infrared(15"only)
IR5 : 5 wires Resistive
Ⓕ : Touch interface code
Ⓔ Ⓕ
121: 12.1" 150: 15.0"
190: 19.0"
A: Aluminium
R: Rear
MC: 3M Capacitive (15",17",19")
GS: S.A.W
10.4"/ 12.1"/ 15.0"/ 17.0"/ 19.0"

LCD MONITOR

Dimensions : DVX104
Dimensions : DVX121
Dimensions : DVX150
Dimensions : DVX170
Dimensions : DVX190
(mm)
(mm)
(mm)
(mm)
(mm)
