I-Inc iK201ABB Technical Specifications

IK Series
©2011 I-Inc. Specifications and design are subject to change without notice. Non-metric weights and measurements are approximate.
All brand, product, service names and logos are trademarks and/or registered trademarks of their respective manufacturers and companies. Screen shot is simulated.
20" Widescreen LCD Display
1600 x 900
20.0" VIEWABLE
RESOLUTION
SCREEN
VESA
TILT
WALL-MOUNTABLE

Technical Specifications

1. Display Size/Type
2. Resolution
3. Aspect Ratio
4. Pixel Pitch
5. Brightness
6. Response Time
7. Contrast Ratio
8. Displayable Colors
9. Viewing Angle (H/V)
10. Color Temperature
1 1. Panel Treatment
12. Horizontal Frequency
13. Vertical Frequency
14. Video Input(s)
15. Speakers
16. Headphone Out
17. Tilt
18. Kensington Slot
19. Input Voltage
20. VESA Mounting
21. Power Consumption
22. Operating Temperature
23. Humidity
2 4. Net Dimensions
25. Net Weight
26. Gross Dimensions
27. Gross Weight
28. Certifications
29. Package Contents
30. UPC Code
31. Warranty
Version 02092011
1000:1
5ms
CONTRAST RATIO
RESPONSE TIME
VGA
INPUT
(IK20 1ABB):
20.0" Widescreen Active Matrix TFT LCD
1600 x 900
16:9
0.2768(H)mm x 0.2768(V)mm
250cd/m²
5ms(Typical)
1000:1 (Typical)
16.7 Million
160°/160°
6500 / 9300 / 5500 / User
Anti-Glare
30kHz - 80kHz
55Hz - 76Hz
VGA
NA
NA
-5° ~ 15°
NA
AC 100 - 2 40V, 50/60Hz
100 x 100 mm
On: 35W(Typ), Standby: <=1W
5°C ~35°C/41°F~95°F
10% - 85%
18.6"(W) x 14.6"(H) x 7.9"(D)
12.3 lbs.
20.6"(W) x 16.8"(H) x 5.7"(D)
16.3 lbs.
UL/CUL, FCC, CB, RoHS
IK201ABB, VGA Cable, Power Cord, User Manual,
Quick Start Guide, Warranty Card
842651005221
1-Year Limited (1-Year Parts/Labor,1-Year LCD/Backlight)
16:9
ASPECT RATIO
RoHS
Compliant
www.i-inc-usa.com
