iH-232HPB
5ms
15000:1
1920x1080
Technical Specifications
1. Display Size/Type
2. Resolution
3. Aspect Ratio
4. Pixel Pitch
5. Brightness
6. Response Time
7. Contrast Ratio
8. Displayable Colors
9. Viewing Angle (H/V)
10. Color Temperature
11. Panel Treatment
12. Horizontal Frequency
13. Vertical Frequency
14. Video Input(s)
15. Speakers
16. Headphone Out
17. Tilt
18. Kensington Slot
19. VESA Mounting
©2009 I-Inc. Specifications and design are subject to change without notice. Non-metric weights and measurements are approximate.
All brand, product, service names and logos are trademarks and/or registered trademarks of their respective manufacturers and companies. Screen shot is simulated.
16:9
HIGH
BRIGHTNESS
23" Widescreen Active Matrix TFT LCD
1920 x 1080 (Full HD)
16: 9
0.266(H)mm x 0.266(V)mm
300cd/m²
5ms (Typical)
X-Contrast 15000:1/DCR (1000:1 Typical)
16.7 Million
170°/160°
Warm, Nature, Cool, User Mode
Anti-Glare Hardcoating
24kHz - 83kHz
56Hz - 75Hz
15-Pin D-SUB (VGA), HDMI w/ HDCP
1W x 2 Channel Built-in Stereo (PC Audio)
3.5mm Stereo
-5°~15°
Yes
100mm x 100mm
23" Widescreen LCD Display
20. Input Voltage
21. Power Consumption
22. Operating Temperature
23. Humidity
24. Net Dimensions
25. Net Weight
26. Gross Dimensions
27. Gross Weight
28. Certifications
29. Package Contents
30. UPC Code
31. Warranty
VGA + HDMI
INPUTS
AC 100~240V, 50/60Hz Autodetect
On: 49W / Standby: 1W / Off: 0.5W
5°C~35°C / 41°F~95°F
10%~85%
19.9"(W) x 16.1"(H) x 6.5"(D)
10.8 lbs.
23.6"(W) x 18.9"(H) x 4.7"(D)
13.4 lbs.
FCC, UL/CUL, RoHS, EnergyStar 5.0,
Windows® 7
iH-232HPB, Power Cable, Audio Cable,
VGA Cable, HDMI to DVI Cable,
User Manual CD-ROM,
Quick Start Guide, Warranty Card
842651003920
1-Year Limited
RoHS
Compliant
www.i-inc-usa.com
Version 07272009
